Transom + tube для мотоциклов Suzuki TS125 (1994)

oem код

название

цена

54111-15D00-000

HUB,FR WHEEL

Hub, front wheel

54731-44B00-000

SPACER,FR HUB BEARING

Spacer, hub bearing Spacer, hub;

08113-62027-000

Подшипник

Bearing, rh Bearing, rh;

08123-62027-000

Подшипник

B1 15x35x11 bearing rh Bearing, lh;

09284-22004-000

SEAL,OIL(22X35X5)

Seal, dust lh (22x35x5) Seal, hub lh;

замена

54711-14D10-000

Вал передний

Model p/r,

54711-14D00-000

AXLE,FR

Model l/m/n

54751-14D00-000

SPACER,FR AXLE,L

Spacer, axle lh Spacer, front axle lh;

54600-14D00-000

BOX ASSY,SPEEDOMETER GEAR

Box assy, speedometer gear

замена

59231-03D00-14C

Cover, front brake disc (red)

Cover, front brake disc (red); Model l/m for 14c

59231-03D00-25Y

COVER,FR BRAKE DISC

Cover, front brake disc (yellow) Cover, front brake disc (yellow); Model l/m/n for 25y

59231-03D00-30H

Cover, front brake disc

Cover, front brake disc (white)

замена

59231-03D00-0NF

Cover, front brake disc

Cover, front brake disc (blue) Cover, front brake disc (blue); Model l/n for 0nf

02142-06167-000

Винт крестовый 6x16

Screw Screw;

09169-06033-000

Шайба

59221-03D01-000

DISC,FR BRAKE

замена

59421-03A10-000

Bolt,rear disc

Bolt, brake disc (8x20) Bolt, disc;

09106-08155-000

BOLT(8X20)

Bolt, brake disc

замена

59421-03A01-000

Болт

55110-03D00-000

Tire, front (2.75x21)

Tire, front (2.75x21); Bridgestone

55200-16510-000

Патрубок

Tube assy, wheel inner Tube, wheel inner;

55261-14540-000

Протектор

Protector, inner tube

замена

55261-16510-000

Protector, inner tube

55311-01A21-000

RIM,FR WHEEL(1.60X21)

Rim, front wheel (1.60x21);

55320-03D10-000

Спицы комплект
