Подножки

Harley Davidson FXDS-CONV GGLP Dyna Glide Convertible (1993)

Harley Davidson
#oem кодцена
3
2851
Деталь SCREW, 3/8-16 X 7/8 hex. cap
3
3214
Деталь SCREW, 3/8-16 X 1-1/4 socket hd. (thd. cutting)
11
4721
Деталь BOLT, 3/8-16 X 1-1/2 hex. hd.(Grade 5 steel)
12
6701
Деталь WASHER, 3/8 X 13/16 X 1/16
13
6718
Деталь WASHER, 1/2 X 1-1/16 X 3/32
14
7038
Деталь LOCKWASHER, 3/8
15
7039
Деталь LOCKWASHER, 7/16
17
7045
Деталь LOCKWASHER, 3/8 high collar
18
7068
Деталь LOCKWASHER,1/2
20
7778
Деталь LOCKNUT, 3/8-16 X 7/16 X 9/16 hex.
21
7782
Деталь LOCKNUT
22
7848W
Деталь JAM NUT, 7/16-20 X 1/4 X 11/16 hex. (Grade 2 steel)
23
7880
Деталь NUT, 1/2-13 X 7/16 X 3/4 hex.(Grade 2 steel)
24
33048-72
Деталь FOOTREST w/ cover (2; 4-BK,EL/M,GE)
33189-63
Деталь COVER, (black) (2; 4-BK,EL/M,GE)
30
49035-03
Деталь MOUNTING PLATE
31
49127-77A
Деталь FOOTREST SUPPORT
32
49165-90
Деталь FOOTREST SUPPORT
36
50639-90A
Деталь SUPPORT RIDER FOOTREST - LEFT HAND (CHROME)
37
50643-82
Деталь FOOTREST w/ cover - right (2-GD/G)
38
50646-82
Деталь COVER, only (black) (2; 4-GD/G)
39
50647-82
Деталь FOOTREST, w/ cover - left (2-GD/G)
40
50649-90
Деталь BRACKET, right, footrest - front
42
50912-72
Деталь SPRING WASHER (as required)
43
52721-90
Деталь UPRIGHT BRACKET, left
44
52729-90
Деталь SUPPORT, left
