Oil pump (2 way)(built before 4/01/03) для снегоходов Polaris SUPERSPORT EDGE - S04NP5BS/A/B (2004)

Москва и регионы России

Oil pump (2 way)(built before 4/01/03)

Polaris SUPERSPORT EDGE - S04NP5BS/A/B

Oil pump (2 way)(built before 4/01/03)

#

oem код

название

цена

1

Pipe, Vinyl

Pipe, Vinyl

2

Clamp-hose(10)

Clamp-hose(10)

3

Screw-air Vent

Screw-air Vent

4

Packing(10)

Packing(10)

5

Asm-oil Pump [incl. 3-10, 16](if Built Before 4/01/03)

Asm-oil Pump [incl. 3-10, 16](if Built Before 4/01/03)

6

Spring-return

Spring-return

7

Collar, Camshaft(10)

Collar, Camshaft(10)

8

Lever-control

Lever-control

9

Гровер (отпуск. по 10 шт)

Гровер (отпуск. по 10 шт)

10

Гайка

Гайка

11

Asm., Screw & Washer

Asm., Screw & Washer

12

Gear, Small

Gear, Small

13

Проставка

Проставка

14

Втулка

Втулка

15

Spacer 1, .15mm ([.15mm] )

Spacer 1, .15mm ([.15mm] )

15

Spacer 2, .3mm ([.3mm] )

Spacer 2, .3mm ([.3mm] )

15

Spacer 3, .6mm ([.6mm] )

Spacer 3, .6mm ([.6mm] )

16

Кольцо

Кольцо

12

Gear

Gear
