Задняя подвеска, передний амортизатор

Arctic Cat ZL 600 EFI SS

Arctic Cat
#oem кодцена
0704-519
0704-758
Shock, Front Arm-assy (ss)
1
2604-094
Body, Shock-rear Arm (ss) (inc. 2-11)
3
1604-653
Ball, Port Plug-ss
4
1604-652
Plug, Port- M5-1.0 X 4.0
5
1604-622
Valve, Back Flow-16098
6
0704-604
Holder, Bender-sub Assy (rb Components)
7
1603-868
Cover, Ss Electrical-frt-assy
8
0623-860
Screw, Ah-bender Holder
9
0623-864
Screw, Cap-hsh M4-0.7x10.0 Lg Ss (4 Per Pack)
10
1604-654
O-ring, Cover-shock Body
11
1604-625
O-ring, Bender Holder
12
1604-533
Elbow, 90 Deg-7/16-20x7/16 W/flare (inc. One No. 13)
13
1604-284
O-ring, Pressure Valve
14
1604-534
45deg. Straight Thread Elbow, Flare Tube (inc. One No. 13)
15
1604-790
Hose, Reservoir-16" Lg-smt Shock
16
1604-728
End Cap, Reservoir-1/8-27 Npt
17
0603-989
Endcap, Reservoir
18
0603-968
O-ring - .139 X 1.484
19
0603-985
Circlip, Reservoir - .063 Dia X 1.77 Id
20
1603-315
Body, Reservoir-4.75" Grooved
21
0704-383
Valve, Pressure - Assy (inc. One No. 13 And 22)
23
0624-433
Screw, Mach - Hsbh 8-32x1/4 Ss
24
0603-986
Piston, Floating - Reservior
25
0603-988
Strap, Piston - Floating - Teflon
26
0603-987
O-ring - .210 X 1.350
27
0423-182
O-ring, -008 (3/16x5/16x1/16) (4 Per Pack)
28
0623-697
Screw, Mach - Hsfh 10-24x3/8 Blk
29
1604-796
Eyelet, Shock - .630 Dia X .950 Lgth
30
1604-659
Rod, Shock - 5.835 Special
31
0704-386
Endcap - Assy (inc. 32)
32
1604-271
O-ring, Outer
33
1604-640
Piston, Blank,w/teflon Band Strap (inc. 34)
34
1604-643
Band, Teflon-endless
35
1604-272
Washer, Top Out -1.125 X .094
36
2603-075
Valve, Shock-1.000 Dia X .010
37
2603-096
Valve, Shock-1.100 Dia X .012
38
2603-127
Valve, Shock-1.250 Dia X .015
39
2603-137
Valve, Shock-1.300 Dia X .015
40
2603-044
Valve, Shock- .700 Dia X .008
41
2603-134
Valve, Shock-1.300 Dia X .008
42
2603-135
Valve, Shock-1.300 Dia X .010
43
2603-125
Valve, Shock-1.250 Dia X .010
44
2603-095
Valve, Shock-1.100 Dia X .010
45
2603-065
Valve, Shock- .900 Dia X .010
46
2603-055
Valve, Shock- .800 Dia X .010
47
0624-523
Washer, Cap-ss
48
1604-632
Magnet-ion-13
49
0624-522
Nut, Special-ss
50
1604-287
Bushing, Shock-.160" Flange (2 Per Pack)
51
1604-502
Sleeve, Eyelet-inner-2.386(99 Pro)
52
3611-007
Decal, Shock-warning
53
4611-444
Decal, Frt Arm Shock "ss"
54
4639-366
S/m Shock Oil-1 Quart (6 Per Pack)
