Rotary Blade (ht3810-k1-3813)
Honda HT3813 SA LAWN TRACTOR, JPN, VIN# HT3813-5000001 TO HT3813-5099999
| # | oem код | название | цена |
|---|---|---|---|
1 | 72512-750-305 SEE PART DETAILS - PRI; BLADE, R. ROTARY | SEE PART DETAILS - PRI; BLADE, R. ROTARY | |
2 | 72513-750-305 SEE PART DETAILS - PRI; BLADE, L. ROTARY | SEE PART DETAILS - PRI; BLADE, L. ROTARY | |
5 | 72620-750-000 HOLDER, BLADE | HOLDER, BLADE | |
7 | 76517-750-000 HOLDER, BLADE | HOLDER, BLADE | |
8 | 90105-VA3-J01 BOLT, HEX. (10X25) | BOLT, HEX. (10X25) | |
9 | 90105-960-710 BOLT, HEX. (10X20) | BOLT, HEX. (10X20) | |
10 | 90502-VA4-640 Шайба (6х20) | Шайба (6х20) | |
11 | 95701-06016-08 Болт (6x16) | Болт (6x16) |
