Throttle body mounting
Polaris Ranger R06RD68AA RANGER XP 4x4 700
| # | oem код | название | цена |
|---|---|---|---|
1 | 7516822 Винт | Винт | |
2 | 5136099 Cover-valve, Mach | Cover-valve, Mach | |
3 | 3021352 Asm-reed W/gasket | Asm-reed W/gasket | |
4 | 7517277 Винт | Винт | |
5 | 5432533 Крышка | Крышка | |
6 | 3021671 Sparkplug-champion Rc7yc3 (4) | Sparkplug-champion Rc7yc3 (4) | |
7 | 1253527 Adaptor-throttle Body | Adaptor-throttle Body | |
8 | 7516734 Винт | Винт | |
9 | 7081193 Clamp-hose | Clamp-hose | |
10 | 1203160 Asm-throttle Body | Asm-throttle Body | |
11 | 7517384 Винт M6x20 | Винт M6x20 | |
12 | 2410720 Датчика положение коленвала | Датчика положение коленвала | |
13 | 5412632 Seal-valve Cover | Seal-valve Cover | |
10 | 2203925 Kit-throttle Body, 1203160 | Kit-throttle Body, 1203160 |
