Инжектор

Arctic Cat Prowler XTZ Baja

Arctic Cat
#oem кодцена
0809-248
Camshaft, Vtwin Rear Cyl Assy
1
0804-031
Cylinder, 950, Vtwin-mach
1
0810-001
Цепь грм
1
0470-686
Throttle Body, H2 (inc. 2-15)
1
0808-227
Cylinder Head Assembly-service (inc. 2-17)
2
0829-062
Dowel, Sleeve-od8 X L7 (2 Per Pack)
2
0810-069
Guide, Chain-vtwin
2
0830-209
Gasket, Head
3
0830-127
Gasket, Base -103.5
3
0810-070
Guide, Chain Tensioner-vtwin
3
0826-001
Screw, Cap Hfh M6 X 1 X 55 (4 Per Pack)
3
0430-072
Sensor, Throttle Position
4
5507-234
O-ring, Tps
4
0809-234
Arm, Valve Rocker Assy-intake (inc. Two No. 5-6)
4
0826-106
Screw, Shs, Chain Tensioner
4
0830-007
O-ring, 21.9 Id X 2.7 W
5
0804-046
Union, Water Hose-
5
0810-004
Adjuster, Tensioner - Assembly
5
0809-240
Screw, Lash Adjustment
5
5507-231
Screw, Tps
6
0430-074
Клапан
6
0827-059
Nut, Hex M5x0.5 (2 Per Pack)
6
0830-134
Gasket,chain Tensioner & Shift, Vtwin
6
8468-612
Screw, Mach-tspnh M6x1.0x12 Cl8.8 Blk
7
0804-030
Union, Water Hose-
7
8468-620
Винт
7
0809-237
Arm, Valve Rocker Assy-exhaust (inc. Two No. 5-6)
7
5507-233
O-ring, Isc
8
5507-227
Bracket, Map Sensor
8
0809-242
Shaft, Rocker Arm-exhaust
8
8400-610
Screw, Cap-hh M6x1x10 8.8 Z&c (4 Per Pack)
8
0804-037
Plug, Cylinder, Vtwin
9
0827-002
Stud, M6 X 1 X 38
9
0828-129
Washer, Aluminum 6x15x1.6
9
0809-241
Shaft, Rocker Arm-intake
9
5507-117
Винт
10
0430-073
Sensor, Map
10
0809-233
Keeper, Valve
10
8424-804
Nut, Hex-flg M8x1.25 Cl8 Rie Sil
11
8424-604
Nut, Hex-flg M6x1.0 Cl8 Rie Sil (4 Per Pack)
11
0809-232
Retainer, Upper, Spring
11
5507-232
O-ring, Map Sensor
12
5507-229
Plate, Isc
12
0809-231
Пружина клапана
12
0829-002
Dowel, Split, 13 X 18
13
0827-018
Stud, M6 X 1 X 32
13
0830-186
УПЛОТНЕНИЕ, ШТОК КЛАПАНА
13
5507-235
O-ring, Base-throttle Body
14
5507-223
Cover, Throttle Housing-efi
14
0809-230
Seat, Valve Spring (4 Per Pack)
14
0827-030
Stud, M6 X 1 X 70
15
0827-031
Stud, M8 X 1.25 X 80
15
0809-229
Valve, Exhaust-27.9mm
15
5507-037
Screw(top Cover) (4 Per Pack)
16
0570-230
Manifold, Intake-assembly (inc. 17-26)
16
0809-228
Valve, Intake-31.6mm
17
0831-066
Plug, Tapered-m14x1.5
17
0423-066
Хамут,50mmx9mm, (40-60 норма)
18
0470-660
Boot, Intake Manifold
18
0809-246
Camshaft, Vtwin-front Cyl-assy
19
0470-688
Injector, Fuel
19
0809-212
Cam Sprocket
20
0826-034
Screw, Cap Hh-m6-1x10.5 W/thd Lock
20
0470-763
Rail, Fuel-h2
21
0470-764
Rail, Fuel-h2
21
0828-004
Washer, Lock Camshaft
22
0829-049
Pin, Solid Dowel-m5x8
22
0470-767
O-ring, Fuel Injector (2 Per Pack)
23
0470-768
Seal-ring, Fuel Injector (2 Per Pack)
23
0809-003
Plate, Cam Retainer
24
0808-077
Plug, Cylinder Head
24
0570-140
Manifold, Intake-mach
25
0570-156
Plenum, Intake-mach
25
0826-007
Screw, Cap Hfh M6 X 1 X 20
26
0808-003
Cap, Valve Inspection
26
0423-371
Screw, Mach M5x12 (4 Per Pack)
27
0826-008
Screw, Mach-tsph M6 X 1 X 20w/threadloc
27
0830-004
O-ring, Inspection Cap
28
0808-090
Bolt, Head, M10x1.25 - 173
28
1623-984
Зажим (2 шт в упаковке)
29
0830-090
O-ring, Intake Manifold
29
0830-147
Washer, Steel, 10x22x2.3 (4 Per Pack)
30
0830-107
Seal, Fastener
31
0826-002
Screw, Cap Hfh M6 X 1 X 30
32
0826-005
Screw, Cap Hfh M6 X 1 X 35
33
0826-006
Screw, Cap Hfh M6 X 1 X 25
34
0217-799
Spark Plug, Cpr8e (cpr8e) (10 Per Pack)
35
0830-120
Seal, Housing, Waterneck
36
0808-008
Крышка термостата
37
0827-031
Stud, M8 X 1.25 X 80
38
8424-804
Nut, Hex-flg M8x1.25 Cl8 Rie Sil
39
0827-002
Stud, M6 X 1 X 38
40
8424-604
Nut, Hex-flg M6x1.0 Cl8 Rie Sil (4 Per Pack)
