Бендикс для мотоциклов Suzuki VZ800 Marauder (2004)

Москва и регионы России

Бендикс

Suzuki VZ800 Marauder

Бендикс

Бендикс

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

20

21

22

23

24

25

26

27

28

29

30

31

32

33

#

oem код

название

цена

1

21200-48840-000

GEAR ASSY,PRI DRIVEN

GEAR ASSY,PRI DRIVEN

Nt:83

2

09160-25037-000

Шайба

Шайба

Washer (25.1x54x2.5) Washer (25x54x2.5);

3

09180-25077-000

SPACER(25X38X6.5)

SPACER(25X38X6.5)

Spacer (25x38x6.5);

4

09263-35017-000

BEARING(35X40X35.8)

BEARING(35X40X35.8)

Bearing (35x40x35.8) Bearing (35x40x35.8);

5

21410-45C03-000

HUB,CLUTCH SLEEVE

HUB,CLUTCH SLEEVE

Hub, sleeve

6

21413-45C00-000

Прокладка муфты

Прокладка муфты

Spacer, sleeve hub

7

21441-37430-000

PLATE,CLUTCH DRIVE

PLATE,CLUTCH DRIVE

Plate, clutch drive Plate, clutch no.1;

8

21442-37401-000

PLATE,CLUTCH DRIVE(T:3.5)

PLATE,CLUTCH DRIVE(T:3.5)

Plate, drive (id:120) Plate, clutch no.2;

9

21451-14A00-000

PLATE,CLUTCH DRIVEN(T:1.6)

PLATE,CLUTCH DRIVEN(T:1.6)

Plate, driven

10

21462-45C00-000

DISC,CLUTCH PRESSURE

DISC,CLUTCH PRESSURE

Disc, pressure Disk, clutch pressure;

11

21471-37400-000

SEAT,WAVE WASHER(T:1.4)

SEAT,WAVE WASHER(T:1.4)

Seat,wave washer (t:1.4) Seat, wave washer;

12

21611-45C02-000

CAM,CLUTCH NO.1

CAM,CLUTCH NO.1

13

21613-45C02-000

CAM,CLUTCH NO.2

CAM,CLUTCH NO.2

14

09116-06135-000

BOLT(6X40)

BOLT(6X40)

Bolt no.1 (6x40);

15

09116-06148-000

BOLT(6X32.5)

BOLT(6X32.5)

Bolt (6x32.5) Bolt no.2 (6x32.5);

16

09140-22011-000

Гайка

Гайка

17

09160-25065-000

Шайба

Шайба

Washer (25x60x2.5);

18

09164-00004-000

Шайба

Шайба

Wave washer Washer (110.5x119x0.9);

19

09164-22008-000

Шайба

Шайба

Washer, wave Washer (22.4x45x2.5);

20

09180-06276-000

SPACER(6.5X9X24.1)

SPACER(6.5X9X24.1)

Spacer (6.5x9x24.1);

21

09440-14038-000

Пружина

Пружина

Spring, propeller shaft Spring, no.1;

22

09440-14039-000

Пружина

Пружина

Spring, no.2

23

23165-21A12-000

RACK,CLUTCH RELEASE

RACK,CLUTCH RELEASE

24

23261-32E10-000

PINION,CLUTCH RELEASE

PINION,CLUTCH RELEASE

Pinion, clutch release

25

23271-31D00-000

Рычаг отключения

Рычаг отключения

Arm, cl rlse Arm, clutch release;

26

09160-15045-000

Шайба

Шайба

Washer (15.5x28x1.0) Washer (15.5x28x1);

27

09263-09001-000

BEARING(9X13X10)

BEARING(9X13X10)

Bearing (9x13x10);

28

09263-12024-000

BEARING(12X16X10)

BEARING(12X16X10)

Bearing, cl rlse upr Bearing (12x16x10);

29

09263-15003-000

Подшипник 15X28X2

Подшипник 15X28X2

Bearing Bearing (15x28x2);

30

09285-10004-000

SEAL,OIL(10X17X5)

SEAL,OIL(10X17X5)

Seal (10x17x5);

31

01547-06167-000

Болт

Болт

Bolt, fastener bracket Bolt, clutch release;

32

16321-48E00-000

GEAR,OIL PUMP DRIVE(NT:47)

GEAR,OIL PUMP DRIVE(NT:47)

Gear, oil pump driven (nt:47);

33

09261-06002-000

PIN(6X6)

PIN(6X6)

Pin (od:6,l:6);
