Трансмиссия для мотоциклов Suzuki DR800 (1992)

oem код

название

цена

24121-44B10-000

SHAFT,COUNTER

замена

24121-44B02-000

Countershaft (nt:13)

Countershaft (nt:13); Model m/n

замена

24221-44B10-000

Gear, 2nd drive (nt:19)

Gear, 2nd drive (nt:19); Model p/r/s

24221-44B20-000

GEAR,2ND DRIVE(NT:19)

Gear, 2nd drive (nt:19)

замена

24221-44B00-000

Gear,2nd drive (nt:19)

Gear, 2nd drive (nt:19); Model m/n

24231-44B02-000

GEAR,3RD DRIVE

замена

24231-44B01-000

Gear,3rd drive,

Gear,3rd drive (nt:20) Gear, 3rd drive (nt:20);

24241-44B01-000

GEAR,4TH DRIVE(NT:23)

Gear, 4th drive (nt:23);

24252-19F00-000

Втулка

Bush, sub t/m driven gr

замена

09300-25023-000

Bush, 5th drive

Bush, 4th drive gear

24251-44B10-000

GEAR,5TH DRIVE(NT:25)

замена

24251-44B01-000

Gear,5th drive (nt:25)

24252-38A10-000

Втулка

Bush, 5th drive gear

замена

24252-38A00-000

Bush,5th drive

Bush, 5th drive gear

09167-25021-000

WASHER,LOCK

Washer, 5th drive gear Washer;

08211-25351-000

Шайба

Washer;

09380-25003-000

RING,SNAP

Circlip Circlip;

09380-25013-000

Пружинное стопорное кольцо

Circlip, 2nd drive

09262-22028-000

Подшипник

Bearing, rh (22x56x16);

09263-17026-000

BEARING(17X30X14)

Bearing, lh Bearing, lh;

24741-44B00-000

Holder,bearing,rh

02122-0612B-000

Болт

замена

02122-06123-000

Болт

Model r/s/t

02122-06127-000

Болт

замена

02122-06128-000

Болт

Model m/n/p

24742-44B00-000

Седло

Retainer, clutch housing

02122-0612B-000

Болт

замена

02122-06123-000

Болт

Model r/s/t

02122-06127-000

Болт

замена

02122-06128-000

Болт

Model m/n/p

24131-44B00-000

Driveshaft

24311-44B10-000

GEAR,1ST DRIVEN(NT:32)

Gear, 1st driven (nt:32)

замена

24311-44B00-000

Gear,1st driven (nt:32)

Gear, 1st driven (nt:32); Model m/n

24312-02F00-000

Втулка

Bush, 1st driven gr

замена

09300-22005-000

Bush 5th drive

Bush, 1st driven gr

09181-20223-000

SHIM(20X32X1)

Washer, sec drive bevel gr

замена

08211-20321-000

Washer,rh

08211-22341-000

Шайба

Plate Washer;

замена

24321-44B10-000

Gear, 2nd driven (nt:30)

Gear, 2nd driven (nt:30); Model p/r/s

24321-44B20-000

GEAR,2ND DRIVEN(NT:30)

Gear, 2nd driven (nt:30)

замена

24321-44B00-000

Gear,2nd driven (nt:30)

Gear, 2nd driven (nt:30); Model m/n

09300-28002-000

BUSH(28X32X11)

Bush, 2nd driven gr

08211-28361-000

Шайба

08331-31289-000

Пружинное стопорное кольцо

замена

08331-31286-000

Стопорное кольцо (пружинное)

24331-44B01-000

GEAR,3RD DRIVEN(NT:24)

замена

24331-44B00-000

Gear,3rd driven

Gear,3rd driven (nt:24) Gear, 3rd driven (nt:24);

24332-27A00-000

Втулка

Bush, 3rd driven gear

09167-28001-000

WASHER,LOCK

Washer, 3rd driven gr,rh Washer, rh;

09167-28002-000

Пластина замка

Washer, 3rd driven gr,lh Washer, lh;

09169-28001-000

Пластина замка

Washer, 3rd driven gr,lh Washer, lh;

24341-44B02-000

GEAR,4TH DRIVEN(NT:22)

замена

24341-44B01-000

Gear,4th driven

Gear,4th driven (nt:22) Gear, 4th driven (nt:22);

24351-44B10-000

GEAR,5TH DRIVEN(NT:20)

замена

24351-44B01-000

Gear,5th driven

Gear, 5th driven (nt:20) Gear, 5th driven (nt:20);

09262-20059-000

Подшипник

Bearing, rh;

09262-25066-000

Подшипник B1 25X62X17

Bearing (25x62x17) Bearing, lh;

09283-25076-000

Сальник

Seal, oil Oil seal, lh;

24751-14A01-000

RETAINER,DRIVE SHAFT OIL SEAL

Holder, oil seal

замена

01500-06103-000

Болт

Bolt, pivot Model r/s/t

01500-0610B-000

Болт

Bolt

замена

01107-06106-000

Плата болта

Model m/n/p

27511-31D00-000

Звездочка

Sprocket (nt:15) Sprocket (nt:15); Model r/s/t

27511-44B00-000

Звездочка

Sprocket (nt:15); Model m/n/p

27512-44B00-000

PLATE,ENGINE SPROCKET

Plate (yellow)

27517-37400-000

Амортизатор

Damper

09111-06039-000

BOLT(6X13)

27600-32C90-116

CHAIN,DRIVE (DID525V11,116L)

замена

27600-32C10-116

Цепь масляного насоса

Chain, drive (525v9x116le) did; Model r/s/t

27600-44B10-116

CHAIN(DID520VL2,116L)

Chain,driven (520vlx116le) did Chain, drive (520vlx116le) did; Model m/n/p
