Transom + tube для мотоциклов Suzuki DR125 (2009)

Москва и регионы России

Transom + tube

Suzuki DR125

Transom + tube

Transom + tube

1

2

3

4

5

6

6

7

8

9

10

11

12

13

14

14

15

15

16

17

18

19

#

oem код

название

цена

1

54111-24H00-000

HUB,FR

HUB,FR

2

54731-24H00-000

SPACER,FR HUB BEARING

SPACER,FR HUB BEARING

3

55311-24H00-000

RIM,FR WHEEL(17X2.15 AL)

RIM,FR WHEEL(17X2.15 AL)

Rim, fr wheel (17x2.15 al);

4

55320-24H00-000

SPOKE SET,FR WHEEL

SPOKE SET,FR WHEEL

5

09285-18002-000

SEAL,OIL(18X32X7)

SEAL,OIL(18X32X7)

Oil seal (18x32x7) Seal, front hub dust;

6

08133-62017-000

Подшипник

Подшипник

Bearing (12x32x10) Bearing, front hub;

7

55110-24H00-000

Tire, front

Tire, front

8

55200-24H00-000

Tube assy, wheel inner

Tube assy, wheel inner

9

55261-24H00-000

Protector,inner

Protector,inner

10

54711-24H00-000

Вал передний

Вал передний

11

54713-24H00-000

Cap, front axle rh

Cap, front axle rh

12

54714-24H00-000

Cap, front axle lh

Cap, front axle lh

13

54741-24H00-000

Spacer, fr axle lh

Spacer, fr axle lh

14

54762-24H00-000

Spacer, axle cap

Spacer, axle cap

15

09139-05034-000

SCREW(5X11.5)

SCREW(5X11.5)

Screw, fr axle cap;

16

08319-3112A-000

Гайка

Гайка

Nut, front axle;

17

54600-24H00-000

BOX ASSY,SPEEDOMETER GEAR

BOX ASSY,SPEEDOMETER GEAR

18

59221-24H00-000

Disc, front brake

Disc, front brake

19

09120-06014-000

Болт

Болт

Screw, disc

замена

09120-06011-000

Болт

Болт

Screw (6x17.5) Screw, front brake disc;
