Fuel tank (e33)

Suzuki (Америка) GSX1300RA

Suzuki (Америка)
#oem кодцена
1-1
44100-15H81-YLF
TANK ASSY,FUEL (GRAY) (BODY COLOR:YLF)
1-2
44100-15H81-YYG
TANK ASSY,FUEL (RED) (BODY COLOR:YYG)
10
44512-16G00
SPACER,FUEL TANK,FR
11
44541-24F01
CUSHION,FUEL TANK,SIDE
12
44543-15H01
CUSHION,FUEL TANK REAR
13
44555-15H00
BRACKET,FUEL TANK REAR NO.3
14
01550-0816A
Болт
15
44550-15H01
BRACKET, FUEL TANK REAR NO.2
16
09139-06191
SCREW (6X22)
17
09139-06191
SCREW (6X22)
18
09320-08071
Подушка
2
68111-47HA0
EMBLEM,S
20
44561-18G00
SPACER,FUEL TANK REAR
21
44530-15H01
BRACKET,FUEL TANK RR NO.1
22
45149-44G01
CUSHION,REAR BRKT NO.2
23
44574-35F00
STAY,FUEL TANK (OPT)
24
44423-15H01
HOSE,FUEL TANK DRAIN
25
44427-15H10
SHIELD,DRAIN HOSE HEAT
3
44200-16870
CAP SET,FUEL TANK
4
09106-05017
BOLT (5X20)
5
44191-15H00
SHIELD,FUEL TANK HEAT NO.1
6
44191-15H10
SHIELD,FUEL TANK HEAT NO.2
7
09139-06204
Винт
8
09160-06054
WASHER (6.5X22X1.6)
9
44511-16G01
CUSHION,FUEL TANK,FR
