E cover (vl800k7/tk7) для мотоциклов Suzuki (Америка) VL800,C,T Boulevard C50 (2009)

E cover (vl800k7/tk7)

Suzuki (Америка) VL800,C,T Boulevard C50

oem код

название

цена

1-1

47110-41F81-YAY

Cover, Frame Rh (black) (e3,e28 For Yay)

1-2

47110-41F81-YHL

Cover, Frame Rh (red) (e3,e28 For Czw)

1-3

47110-41F81-YD8

Cover, Frame Rh (silver) (e3,e28 For Czz)

1-4

47110-41FA1-YAY

Cover, Frame Rh (black) (vl800t E3,e28)

1-5

47110-41F91-YAY

Cover, Frame Rh (black) (e33 For Yay)

1-6

47110-41F91-YHL

Cover, Frame Rh (red) (e33 For Czw)

1-7

47110-41F91-YD8

Cover, Frame Rh (silver) (e33 For Czz)

1-8

47110-41FB1-YAY

Cover, Frame Rh (black) (vl800t E33)

2-1

47210-41F80-YAY

Cover, Frame Lh (black) (for Yay)

2-2

47210-41F80-YHL

Cover, Frame Lh (red) (for Czw)

2-3

47210-41F80-YD8

Cover, Frame Lh (silver) (for Czz)

2-4

47210-41FA0-YAY

Cover, Frame Lh (black) (vl800t)

3-1

68131-41F40

.emblem, C50

3-2

68131-41F50

.emblem, C50t (vl800t)

47166-41F00

Shield, Frame Cover Rh

Cover, Side Lower Rh

Cover, Side Lower Lh

Шайба

.cushion, 8.5x20x8

Cover, Side Rear Rh (black)

47241-41F00-019

Cover, Side Rear Lh (black)

Screw, Brace

Cushion, Brace

.grommet

Cushion, Lower

Cushion Box Front

Lock Set, Fuel Lid

Гайка

Plug ( Rerer To Fig.41e(i- 8) For Model K9 )
