Transmission (model k4/k5/k6)

Suzuki (Америка) RM125

Suzuki (Америка)
#oem кодцена
1-1
24120-36F10
Shaft, Counter (nt:14) (model K4)
1-2
24120-36F11
Shaft, Counter (nt:14) (model K5/k6)
2
24221-36F10
Gear, 2nd Drive (nt:16) ()
3
24231-36F00
Gear, 3rd & 4th Drive (nt:18/20)
4
24251-43D20
Gear, 5th Drive (nt:19) ()
5
24261-43D01
Gear, 6th Drive (nt:20) ()
6
24262-36F00
Bush, 6th Drive ()
7
09167-22024
Washer Lock, 6th Drive ()
8
09181-22139
Washer (22x28x1.0) ()
9
09262-17040
Bearing, Drive Shaft Rh (17x35x10)
10
09300-22008
Bush (22x27x0.5) ()
11
09380-22006
Circlip ()
13
09262-20122
Bearing, Crank Balancer (20x47x12)
14
24131-36F00
Shaft, Drive ()
15
24311-36F00
Gear, 1st Driven (nt:29) ()
16
24321-36F01
Gear, 2nd Driven (nt:27) ()
17
24331-36E01
Gear, 3rd Driven (nt:26) ()
18
24341-36E00
Gear, 4th Driven (nt:24) ()
19
24351-36F00
Gear, 5th Driven (nt:20) ()
20-1
24361-36E03
Gear, 6th Driven (nt:19) (model K4)
21
09160-20074
Washer, 2nd Driven Lh (20x30x3)
22
09181-17167
Washer (17x26x1) ()
23
09181-22167
Washer, 6th Drive ()
26
09300-17012
Bush, 1st Driven ()
28
09300-22018
Bush, 3rd & 4th Driven ()
30
24741-20A00
Retainer, Bearing ()
31
24741-21A00
Retainer, Shift Cam Bearing ()
33
09262-20110
Bearing, Drive Shaft Lh (20x52x12.5)
34
09289-28012
Seal, Drive (28x38x7.5) ()
35
02112-0610B
Screw ()
36
02122-0612A
Винт
37-1
26260-43D01
Gear, Kick Idle (nt:26) (model K4)
38
09181-17130
Washer, Kick (17x24x0.5) ()
39
08331-3117A
Circlip ()
40-1
27511-14111
Sprocket, Engine (nt:12) ()
40-2
27511-14121
Sprocket, Engine (nt:13) (opt)
41
27531-43D00
Spacer ()
42
27600-43D01-114
Chain Assy (did520dma2, 114le) ()
43
27620-43D00
Joint Set, Chain (opt)
44
09280-20006
O Ring (d:1.9, Id:19.8) ()
45
09380-20007
Circlip, Engine Sprocket ()
