Глушитель

KTM 2019 300 XC ENGINE

KTM
#oem кодцена
1
0019050106S
hex lobe countersunc screw M5x10 - 10.9
10*
0912060253
AH SCREW DIN0912-M 6X25
11
54637067000
SPRING SLEEVE
12*
55537066000
Overload spring
13*
0912060083
AH SCREW DIN0912-M 6X 8
14*
55537065000
Adjusting lever cmpl.
15*
55537080000
Post mount cmpl.
16*
55537064044
Gear segment right cmpl.
17
54837064150
GEAR SEGMENT L/S 250 07
18*
50437023100
exaust flap bushing
19
0770150151
O-RING 15,00X1,50 VITON
2
54837062000
RETAINING PLATE R/S 07
20*
55537020000
Control hatch 250
21*
014580060166
SHCS ISO 14580 M6x16
22*
0137060003
spring washer DIN 137 B - 6
23*
0021060003
WASHER DIN9021-A 6,4
25
0014050123
HH COLLAR SCREW M 5X12 WS=6
26
0349000050
WASHER DIN7349-5X15X2
27
55437058000
BEARING SUPPORT
28*
0025050256S
HH COLLAR SCREW M5X25 ISA30
29*
55537068000
Bearing sleeve
3
54837063000
RETAINING PLATE L/S 07
31*
55537050444
Centrifugal force governor cmpl.
36
54637098100
BALL BEARING 626LLBC3/5K
4
0770160021
O-RING 16,00X2,00 VITON
40
0014050203
HH COLLAR SCREW M 5X20 WS=6
43
54837075000
SPRING GUIDE 250/300
44
0770021120
O-RING 12,37X2,62 NBR70
45
0770240020
O-RING 24,00X2,00 NBR70
46
54837069000
ADJUST. SPRING 2003
47
54837072100
AUXILIARY SPRING HARD, GREEN
47
54637072300
AUXILIARY SPRING MID., YELLOW
47
54837072000
AUXILIARY SPRING SOFT, RED
48
54637071200
SPRING INSERT
5
55437061044
CONTR.VALVE 250 LEFT KPL.
50
47237056000
angle lever
51
0988101610
SHIM WASHER DIN988 10X16X1
52
0618101410
needle sleeve HK 1010 10x14x10
53
55437057100
ADJUSTING LEVER 250/300
6
55437062044
CONTR.VALVE 250 RIGHT KPL.
60
55437095044
CONNECTING ROD CPL.
61
50237195055
SECURING DIN-71805-S-8
