Lubrica ting system для мотоциклов KTM 2018 50 SX MINI ENGINE (2018)

Москва и регионы России

Lubrica ting system

KTM 2018 50 SX MINI ENGINE

Lubrica ting system

#

oem код

название

цена

1

OIL TANK CPL. 50SX MINI 2012

OIL TANK CPL. 50SX MINI 2012

2

RUBBER GROMMET 6X9X13MM 04

RUBBER GROMMET 6X9X13MM 04

3

ANGLE CONNECT ION EXPANS. TANK

ANGLE CONNECT ION EXPANS. TANK

4

RUBBER SLEEVE D=8MM OPEN

RUBBER SLEEVE D=8MM OPEN

6

SCREW FOR PLASTIC K60X20 SW6

SCREW FOR PLASTIC K60X20 SW6

7

HH COLLAR SCREW M6X10 TX30

HH COLLAR SCREW M6X10 TX30

8

HOSE 5X9MM

HOSE 5X9MM

9

OIL TANK SCREW SX MINI

OIL TANK SCREW SX MINI

20

Масляный насос

Масляный насос

21

O-RING 19,10X1,60 NBR 70

O-RING 19,10X1,60 NBR 70

22

AH SCREW DIN0912-M 5X16

AH SCREW DIN0912-M 5X16

23

PREFORM. HOSE CARB.-PUMP 2X5MM

PREFORM. HOSE CARB.-PUMP 2X5MM

24

YDNAC CLAMP 10101 (10,4MM)

YDNAC CLAMP 10101 (10,4MM)

25

CLAMP 5 FOR OIL PUMP

CLAMP 5 FOR OIL PUMP

30

SPACER FOR OIL PUMP GEAR

SPACER FOR OIL PUMP GEAR

31

NEEDLE PIN DIN5402 NRB3X7,8 G2

NEEDLE PIN DIN5402 NRB3X7,8 G2

32

OIL PUMP DRIVE WHEEL

OIL PUMP DRIVE WHEEL

33

CIRCLIP DIN0471-19X1,2

CIRCLIP DIN0471-19X1,2

34

HH COLLAR NUT M10X1,25 WS=13

HH COLLAR NUT M10X1,25 WS=13
