Бугель

KTM 1290 SUPERDUKE R BLACK CHASSIS

KTM
#oem кодцена
1
6130403004433
Swing Arm Cpl.
2
61304050000
Splash Protector
3
61304051000
Bracket Splash Protector
4
61304060000
Chain Sliding Guard Front
5
61304070000
Chain Sliding Guard Rear
6
69004037144
Swing Arm Bolt
7
60004038000
Collar Nut M19x1, 5 Ws=27mm 03
8
60004017000
Screw M14x1, 5 L=73mm 03
9
83008000012
Special Screw M6x12x3
10
76004142000
Bolt Brake Saddle Bracket
11
61304042000
Cable Support
12
69008021060
Special Screw M5x17
13
61310021000
Hh Collar Screw M16x1, 5x55
14
0025050126
Hh Collar Screw M5x12 Tx30
15
46104066050
Bush For Chainslider Guard 02
16
0081050141
Ejot Pt Screw 50x14 Wn 1451
17
0760304073
Shaft Seal Ring 30x40x7
18
60004034000
Bucket F. Shaft Seal Ring 03
19
69004032000
Inner Ring Jr 20x25x56, 5
20
60004032000
Inner Ring Jr20x25x38, 5 03
21
60004031000
Needle Bush Hk2526b 03
22
60004033000
Stop Disk 03
24
61304030010
Sticker Swing Arm Black
99
69004230010
Swing Arm Rep. Kit 08-14
