Monoshock disassembled ref# 48 - 85 для мотоциклов KTM 625 SMC CHASSIS USA 06 (2006)

Monoshock disassembled ref# 48 - 85

KTM 625 SMC CHASSIS USA 06

oem код

название

цена

46810063

Spring Retainer D=58, H=13, L=15

46811208

Rubber Cap "do Not Open"

50*

50180342S1

Shock Absorber Fluid 5 Lt '03

46811216

Rebound Bush Plane H=6, 5

Spacer 35x14x10

Shim 12x26x0, 20

Shim 12x28x0, 20

Shim 12x30x0, 20

Shim 12x40x0, 20

Shim 12x40x0, 25

Shim 12x32x0, 15

Shim 12x34x0, 15

Shim 12x36x0, 15

Shim 12x38x0, 15

Backplate 12x16x0, 30

46810490

Shim 12x24x0, 20

46810519

Shim 12x28x0, 15

46810638

Backplate 12x18x0, 30

46811636

Pressure Ring 32x28, 25x0, 30

46811218

Piston 6+6xd=7 Ba

46810035

O-ring Viton 37, 82x1, 78

Piston Ring 8x46

Bleed Screw M6x0, 5

Ring 12x24x2, 5

Shim 6x14x0, 1

Shim 6x16x0, 1

Shim 6x18x0, 1

Backplate 6x8, 5x0, 30

46180060

Piston Rod Nut Cpl. M12x1

46810340

O-ring Nbr 45x2

46811453

Reservoir Screw L=123 Grey
