Frame body

Honda PC800 Pacific Coast

Honda
Frame body
#oem кодцена
1
17404-PD6-003
Clamp, bypass hose
2
19601-MR5-000
Cover, engine heat
3
19602-MR5-000
Plate, r
4
19603-MR5-000
Plate, l
5
19612-MR5-000
Накладка
6
19613-MR5-000
Накладка
7
19616-MR5-000
Plate, air guide
8
19631-MR5-000
Rubber, r
9
19632-MR5-000
Rubber, l
10
33613-KG1-610
Манжета
11
90522-028-000
Washer, chain case setting
12
50100-MR5-620
Body comp
13
50201-KE5-000
Резина
14
50210-MR5-000
Sub-frame
15
50251-MR5-000
Colr, engine setting
16
50252-MR5-000
Collar, engine mount
17
50253-MR5-000
Collar, engine mount
18
50257-MR5-000
Collar, engine mount
19
50258-MR5-000
Держатель
20
50260-MR5-000
Опора
21
64206-MR5-790
Bumper, r. fr.
замена
64206-MR5-000
Bumper, r. fr.
22
64216-MR5-000
Bumper, l. fr.
23
74813-MR5-000
Striker, tailgate
24
81363-MR5-000
Rubber g, seal
25
90003-GC3-000
Bolt, rr. fender
26
90029-888-000
Bolt, flange, 6x16 (ct200)
27
90103-GA6-000
Bolt (10x153)
28
90109-SB6-000
Болт
29
90153-MR5-000
Bolt (10x282)
30
90157-MN8-000
Bolt, socket (10x17)
31
90320-GC3-000
Nut, spring, 5mm
32
90690-GHB-641
Clip, cable, 10mm
33
90690-GHB-651
Clip, cable, 15mm
34
90690-GHB-661
Clip, cable, 20mm
35
90841-001-000
Голвка вилта
36
94071-05080
Nut-washer
37
94050-08080
Гайка
38
94050-10080
Гайка
40
95701-080-160-8
Болт
41
95701-080-180-8
Болт
42
95701-100-550-8
Болт
43
95801-080-800-8
Болт
44
95701-100-250-8
Болт
замена
95801-100-250-8
Болт
45
95801-100-400-8
Болт
