Gl1100a radio для мотоциклов Honda GL1100A Gold Wing Aspencade (1982)

Москва и регионы России

Gl1100a radio

Honda GL1100A Gold Wing Aspencade

Gl1100a radio

Gl1100a radio

1

2

3

4

4

4

5

6

7

8

9

10

11

12

13

14

15

16

17

17

18

19

20

21

22

22

22

23

23

24

25

26

27

28

29

30

31

32

33

34

34

35

36

37

37

38

39

40

41

42

43

44

#

oem код

название

цена

1

Grommet, air bypass

Grommet, air bypass

2

Harn,radio sw.sub

Harn,radio sw.sub

3

Harness,radio

Harness,radio

4

Хомут

Хомут

5

Lock, filler lid

Lock, filler lid

6

Коробка предохранителей

Коробка предохранителей

7

Fuse,0.5a

Fuse,0.5a

8

Fuse,4a

Fuse,4a

9

Controller, radio

Controller, radio

10

Pl,controler base

Pl,controler base

11

Cap (5mm)

Cap (5mm)

12

Lid,controler

Lid,controler

13

Spring,lock

Spring,lock

14

Speaker r.assy.

Speaker r.assy.

15

Speaker l.assy.

Speaker l.assy.

16

Amp,power

Amp,power

17

Sub feeder,ant.

Sub feeder,ant.

18

Antena assy.

Antena assy.

19

Element,antenna

Element,antenna

20

Feeder, antenna

Feeder, antenna

21

Grom,audio cord

Grom,audio cord

22

Tie,repeat

Tie,repeat

23

Grommet,antenna

Grommet,antenna

24

Stay,antenna

Stay,antenna

25

Indicator,radio

Indicator,radio

26

Brkt,rear

Brkt,rear

27

Rub,mtg.(radio)

Rub,mtg.(radio)

28

Tuner, radio

Tuner, radio

29

Collar,mtg.

Collar,mtg.

30

Cord,rad/pa.joint

Cord,rad/pa.joint

31

Sw,radio select

Sw,radio select

32

Collar,radio sw.

Collar,radio sw.

33

Cap,socket bolt

Cap,socket bolt

34

Nut, flange cap, 5mm

Nut, flange cap, 5mm

35

Bolt,hex.soc.5x20

Bolt,hex.soc.5x20

36

Bolt,soc.10x25

Bolt,soc.10x25

37

Nut,wing m5x0.8

Nut,wing m5x0.8

38

Bolt-washer, 6x12

Bolt-washer, 6x12

39

93892-040-100-8

Винт с шайбой

Винт с шайбой

4X10

40

93893-040-200-8

Винт с шайбой

Винт с шайбой

4X20

41

94001-040-800-S

Гайка

Гайка

HEX., 4MM

42

Гайка

Гайка

FLANGE, 4MM

43

Шайба

Шайба

PLAIN, 4MM

44

Шайба

Шайба

SPRING, 4MM
