Stand + step для мотоциклов Honda CL350 CL350 (0)

Москва и регионы России

Stand + step

Honda CL350 CL350

Stand + step

Stand + step

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

15

16

17

18

19

20

21

22

22

23

24

25

26

27

28

29

30

31

32

32

33

33

33

34

35

35

36

36

37

37

37

38

38

38

39

39

40

40

41

41

41

41

42

43

43

43

44

#

oem код

название

цена

1

Rod rear brake

Rod rear brake

Use up to Frame SN 1022920

2

Соединитель

Соединитель

3

Pin b, brake rod joint

Pin b, brake rod joint

Use up to Frame SN 1022920

4

Пружина

Пружина

5

Nut b, brake rod adjusting

Nut b, brake rod adjusting

6

Pedal comp,brake

Pedal comp,brake

7

Collar,brakepedal

Collar,brakepedal

8

Spring.brk.pedal

Spring.brk.pedal

9

50500-290-000-B

Stand,main

Stand,main

10

Spring,main stand

Spring,main stand

11

Rubber b, stand stopper

Rubber b, stand stopper

12

Shaft,stand pivot

Shaft,stand pivot

13

Bar,side stand

Bar,side stand

14

Spring d, side stand

Spring d, side stand

Use up to Frame SN 1046888

15

Палец

Палец

16

50610-290-670-B

Bar, step *nh1*

Bar, step *nh1*

17

50610-290-670-B

Bar, step *nh1*

Bar, step *nh1*

18

50616-283-020-B

Arm,r step

Arm,r step

19

Пружина

Пружина

20

50642-283-020-B

Arm,l step

Arm,l step

21

Пружина

Пружина

22

Rubber,step

Rubber,step

23

Washer,pillion

Washer,pillion

24

Bracket,pillion

Bracket,pillion

25

Bracket 3,pillion

Bracket 3,pillion

26

Pin b

Pin b

27

Bar,pillion

Bar,pillion

28

Rubber,pillon

Rubber,pillon

29

Screw,pivot

Screw,pivot

30

Bolt,brake pivot

Bolt,brake pivot

31

Wash,sub 14.5x2mm

Wash,sub 14.5x2mm

32

Болт

Болт

замена

Bolt,hex 6x36

Bolt,hex 6x36

33

Bolt, hex., 8x16

Bolt, hex., 8x16

34

Bolt, hex., 8x25

Bolt, hex., 8x25

35

Bolt, hex., 10x25

Bolt, hex., 10x25

36

94001-062-000-S

Гайка

Гайка

HEX., 6MM

37

94001-100-000-S

Гайка

Гайка

HEX., 10MM

38

Шайба

Шайба

PLAIN, 6MM

39

Шайба

Шайба

PLAIN, 8MM

40

Washer, plain, 10mm

Washer, plain, 10mm

41

Шайба

Шайба

SPRING, 8MM

42

Штифт

Штифт

SPLIT, 1.6X12

43

Штифт

Штифт

44

Pin, split, 2.5x30

Pin, split, 2.5x30
