Transom + tube для мотоциклов Honda CB125T (1982)

Москва и регионы России

Transom + tube

Honda CB125T

Transom + tube

Transom + tube

1

1

2

4

5

6

7

8

9

10

10

11

12

13

14

15

16

17

18

19

19

20

20

#

oem код

название

цена

1

Tube,wheel

Tube,wheel

1

Tube (275/300-18)

Tube (275/300-18)

замена

Tube (2.75/3.60-18)

Tube (2.75/3.60-18)

2

Ось колеса

Ось колеса

замена

Ось колеса

Ось колеса

4

Collar,wheel side

Collar,wheel side

5

Cap,fr.wheel

Cap,fr.wheel

6

Seat,wheel cap

Seat,wheel cap

7

Collar,distance

Collar,distance

8

Wheel comp.,fr.

Wheel comp.,fr.

9

Retainer, gear box

Retainer, gear box

10

Tire,fr.

Tire,fr.

10

Tire, fr. (3.00-18)

Tire, fr. (3.00-18)

замена

Superceded

Superceded

11

Box,spdmt gear

Box,spdmt gear

12

Disk,fr.brake

Disk,fr.brake

13

Bolt,flange,8x87

Bolt,flange,8x87

14

Гайка (14mm)

Гайка (14mm)

замена

Nut, rr. (14mm)

Nut, rr. (14mm)

15

Nut, flange (self-lock) (m8x1.25)

Nut, flange (self-lock) (m8x1.25)

16

Dust seal (22x42x7)

Dust seal (22x42x7)

17

Dust seal (40x50x5)

Dust seal (40x50x5)

замена

Dust seal (40x50x5)

Dust seal (40x50x5)

18

Screw, oval (5x16)

Screw, oval (5x16)

19

Washer, plain, 14mm

Washer, plain, 14mm

20

96120-630-201-0

B/brg rad n/com

B/brg rad n/com
