Rear wheel complete assy для мотоциклов Honda ATC250ES Big Red (1986)

Москва и регионы России

Rear wheel complete assy

Honda ATC250ES Big Red

Rear wheel complete assy

Rear wheel complete assy

1

2

3

4

4

5

6

6

7

7

8

8

9

9

9

9

10

10

#

oem код

название

цена

1

Hub assy.,l.rr.

Hub assy.,l.rr.

2

Hub assy.,r.rr.

Hub assy.,r.rr.

замена

Hub assy.,r rear

Hub assy.,r rear

3

Rim comp,wheel

Rim comp,wheel

4

Superceded

Superceded

5

Клапан обода

Клапан обода

6

Bolt, wheel (10x36)

Bolt, wheel (10x36)

7

Гайка

Гайка

замена

Nut,axle,18mm

Nut,axle,18mm

8

Гайка

Гайка

9

Oil seal20x28.2x5

Oil seal20x28.2x5

9

Oil seal,20x28.2x

Oil seal,20x28.2x

10

Pin, split, 4.0x30

Pin, split, 4.0x30
