WIRING HARNESS, MAIN - FLRT (9 OF 9)
Harley Davidson FLRT 1MCP FREEWHEELER (2022)
| # | oem код | название | цена |
|---|---|---|---|
1 | 10177 Деталь CABLE STRAP,X-MAS TREE MOUNT | anchored | Деталь CABLE STRAP,X-MAS TREE MOUNT | anchored | |
2 | 72499-07 Деталь WIRE SEAL,#20-22 AWG,GREEN | 20-22 AWG (green) | Деталь WIRE SEAL,#20-22 AWG,GREEN | 20-22 AWG (green) | |
3 | 73102-96BK Деталь HSG PIN 2 PLC | two-way pin (black) | Деталь HSG PIN 2 PLC | two-way pin (black) | |
4 | 73190-96 Деталь TERMINAL,PIN,#16-20AWG | pin, 16-20 AWG | Деталь TERMINAL,PIN,#16-20AWG | pin, 16-20 AWG | |
5 | 83944-09 Деталь TERMINAL, SOCKET, #18-20 AWG | socket, 18-20 AWG | Деталь TERMINAL, SOCKET, #18-20 AWG | socket, 18-20 AWG | |
6 | 69200461 Деталь HOUSING,8-WAY,SCKT | eight-way socket | Деталь HOUSING,8-WAY,SCKT | eight-way socket | |
7 | 69201301 Деталь SEAL,CONN/TERM,X | 20-22 AWG (green) | Деталь SEAL,CONN/TERM,X | 20-22 AWG (green) | |
8 | 69201396 Деталь TERMINAL,SOCKET,#20 AWG | socket, 20 AWG | Деталь TERMINAL,SOCKET,#20 AWG | socket, 20 AWG | |
9 | 69201400 Деталь HOUSING,2-WAY, SOCKET,BK,CPA | two-way socket (black) | Деталь HOUSING,2-WAY, SOCKET,BK,CPA | two-way socket (black) | |
10 | 69201401 Деталь SECONDARY LOCK 2-WAY SOCKET | two-way socket | Деталь SECONDARY LOCK 2-WAY SOCKET | two-way socket | |
11 | 69201404 Деталь ANCHOR,CONNECTOR | anchored | Деталь ANCHOR,CONNECTOR | anchored | |
12 | 69201405 Деталь RESISTOR PACK | Деталь RESISTOR PACK | |
13 | 69201779 Деталь CONNECTOR,IMU | four-way socket (black) | Деталь CONNECTOR,IMU | four-way socket (black) | |
14 | 69201814 Деталь TERMINAL,SOCKET | socket | Деталь TERMINAL,SOCKET | socket |
