Кофры боковые

Harley Davidson FLHTCU8 103 ANV 1PRM_ANV CVO ULTRA CLASSIC ANV (2013)

Harley Davidson
#oem кодцена
1
2478
SCREW NO. 10-24 X 1/2 TORX BUTTON HD.
2
2524B
SCREW NO. 8-32 X 5/16 TORX BUTTON HD., SELF-TAPPING
3
3592A
SCREW NO. 8-32 X 1/2 TORX TRUSS HD. W/ DOGPOINT LEAD (STAINLESS)
4
3593
SCREW NO. 8-32 X 5/16 TORX TRUSS HD.
5
3595
SCREW NO. 6-32 X 1/4 TORX HD., W/LOCKPATCH
6
3612
SCREW NO. 10-16 X 1/2 TORX PAN HD., SELF-TAPPING
7
4616
Винт
8
4630
Винт
9
5233
SCREW #10-16 X 1/2 HI-LO, TORX HD T-25
10
6229W
WASHER 5/16 X 1-1/16 X 3/64
11
7608
NUT NO. 8-32 X 1/8 X 11/32 (GRADE 2)
12
7624
LOCKNUT NO. 10-24 X 1/4 X 3/8
13
10065
CABLE STRAP
14
10120
Зажим
15
10302
E-CLIP
16
11468
Уплотнитель резиновый
17
53482-93
RUB BAR LEFT, REAR (PLASTIC)
17
53483-93
RUB BAR RIGHT, REAR (PLASTIC)
18
53567-93
CHECK STRAP
19
53597-07
ACTUATOR POWER LOCK
20
53986-07
LOCK (SPECIFY KEY CODE)
21
59289-92
REFLECTOR AMBER, RIGHT (HDI, ASIA-PACIFIC)
21
59290-92
REFLECTOR AMBER, LEFT (HDI, ASIA-PACIFIC)
22
68042-99
SCREW NO. 8-32 X 3/8 TORX HD.
23
72651-11
HARNESS IPOD, RIGHT
24
73198-96
CONNECTOR ANCHOR
25
74102-98BK
PIN HOUSING 2-WAY (BLACK)
26
74112-98BK
HOUSING 2-WAY SOCKET
27
74142-98
SECONDARY LOCK 2-WAY, PIN
28
74152-98
SOCKET LOCK 2-WAY
29
74190-98
TERMINAL PIN, 16-20 AWG
30
74191-98
SOCKET TERMINAL
