Задний бампер

Harley Davidson FLHXSE 1PZ8 CVO STREET GLIDE (2010)

Harley Davidson
#oem кодцена
1
2952A
SCREW 1/4-20 X 1/2 SEMS TRUSS HD.
2
3684
SCREW 5/16-18 X 1 TORX PAN HD.
3
6703
WASHER 1/4 X 5/8 X 1/16
4
7434
WASHER 1/4 X 1-29/64 X 1/16 NYLON
5
7499
NUT 1/4-20 LARGE FLANGE
6
7531
LOCKNUT 5/16-18 X 9/32 X 1/2 FLANGE
7
7686
LOCKNUT 1/4-20 X 5/16 X 7/16
8
7716
LOCKNUT 1/4-20 X 7/16 FLANGE
9
7880
NUT 1/2-13 X 7/16 X 3/4 (GRADE 2)
10
11891
Проставка
11
59174-99
STUD PLATE
12
59768-97
FENDER SEAT NUT KIT
13
59786-01
BOSS FENDER MOUNTING, INNER
14
59788-01
Шайба
15
59818-09
STUD PLATE
16
60463-09A
FENDER REAR (PRIME)
16
59669-10DEH
FENDER REAR (CANDY CONCORD)
16
59669-10DEK
FENDER REAR (SPICED RUM)
16
59669-10DEM
FENDER REAR (TEQUILA SUNRISE)
17
60465-09
FASCIA REAR FENDER (PRIME)
17
60465-10DEH
FASCIA REAR FENDER (CANDY CONCORD)
17
60465-10DEK
FASCIA REAR FENDER (SPICED RUM)
17
60465-10DEM
FASCIA REAR FENDER (TEQUILA SUNRISE)
17
60614-09
TAPE PROTECTIVE, REAR FENDER (NOT ILLUSTRATED)
18
60919-09
PLATE STIFFNER
19
91140-09
BRACKET FENDER TO SADDLEBAG SUPPORT
20
60472-09A
FENDER REAR (PRIME) (CANADA, HDI, ENGLAND, JAPAN)
20
59670-10DEH
FENDER REAR (CANDY CONCORD) (CANADA, HDI, ENGLAND, JAPAN)
20
59670-10DEK
FENDER REAR (SPICED RUM) (CANADA, HDI, ENGLAND, JAPAN)
20
59670-10DEM
FENDER REAR (TEQUILA SUNRISE) (CANADA, HDI, ENGLAND, JAPAN)
