PRIMARY HOUSING

Harley Davidson FLTR3 CVO (Japan only) (2009)

Harley Davidson
#oem кодцена
1
786A
BOLT, 5/16-18 X 2-1/4 hex hd. (Grade 5) | PV
2
791A
SCREW, 3/8-18 X 2-1/4 hex flange hd. (Grade 5) | PV
3
1062
SCREW, 1/4-20 X 5/8 TORX hd. (Grade 8) | PV
4
1780
SCREW | PV
5
4813A
SCREW, 1/4-20 X 1-3/8 knurled hd., w/lockpatch | PV
6
9231
BEARING | PV
7
11105
O-RING | PV
8
12052A
SEAL | PV
9
16583-00A
DOWEL BUSHING | PV
10
17369-06
GASKET SERVICE KIT (1K, 5K, 10K), w/ 11105 & seal clutch cover | PV
11
24754-75A
DOWEL BUSHING, starter | PV
12
34901-07
GASKET, primary cover | PV
13
34948-08
GASKET, primary housing to case | PV
14
39929-06B
CHAIN TENSIONER ASSEMBLY | PV
15
42642-00A
BUSHING | PV
16
60328-98B
PLUG, magnetic drain w/ 11105 | PV
17
60850-08A
INNER PRIMARY HOUSING, w/ 9231, 12052A, 16583-00A, 42642-00, 60328-98B & 60678-85 (Domestic, Canada & HDI) (granite) | PV
60432-07A
INNER PRIMARY HOUSING, w/ 9231, 12052A, 16583-00A, 42642-00, 60328-98B & 60678-85 (Japan) (black) | PV
18
60553-07A
COVER PRIMARY (CHROME) | PV
19
60678-85
RETAINING RING | PV
20
60766-06
COVER, clutch (chrome) | PV
21
791A
SCREW, 3/8-18 X 2-1/4 hex flange hd. (Grade 5) | PV
22
60818-07
SLEEVE, dampener (Japan only) - INTERNATIONAL MODELS ONLY | PV
