Задний бампер

Harley Davidson FLHTCU4 CVO (Japan only) (2009)

Harley Davidson
#oem кодцена
1
2952A
SCREW, 1/4-20 X 1/2 SEMS truss hd. | PR
2
3684
SCREW, 5/16-18 X 1 TORX pan hd. | PR
3
6703
WASHER, 1/4 X 5/8 X 1/16 | PR
4
7434
WASHER, 1/4 X 1-29/64 X 1/16 nylon | PR
5
7531
LOCKNUT, 5/16-18 X 9/32 X 1/2 flange | PR
6
7686
LOCKNUT, 1/4-20 X 5/16 X 7/16 | PR
7
7880
NUT, 1/2-13 X 7/16 X 3/4 (Grade 2) | PR
8
10006
CABLE STRAP, lighting harness | PR
9
10183
CLIP, t-stud | PR
10
10184
CLIP, t-stud | PR
11
58702-09
FENDER, rear (prime) | PR
59583-09BYW
FENDER, rear (Autumn Haze) | PR
59583-09CZB
FENDER, rear (Stardust Silver) | PR
59583-09DAA
FENDER, rear (Ruby Red) | PR
12
59174-99
PLATE, stud | PR
13
59423-03
CLOISONN`E, rear fender | PR
59699-06
PROTECTIVE TAPE, rear fender (not illustrated) | PR
14
59768-97
NUT KIT, seat, w/ retention washer | PR
15
59786-01
BOSS, fender mounting, inner | PR
16
59788-01
WASHER | PR
17
67266-94
GROMMET, 1/2 in. I.D. (nylon) | PR
18
68772-09A
HARNESS rear lighting (not illustrated) w/ 10006, 70522-06B, 73156-96BK, 73158-96BK & 73191-96 | PR
19
70522-06B
CONDUIT self-adhesive | PR
20
73156-96BK
SOCKET HOUSING, 6-place | PR
21
73158-96BK
SOCKET HOUSING, 8-place | PR
22
73191-96
SOCKET TERMINAL, #16-20 AWG | PR
23
91140-09
BRACKET, fender to saddlebag support | PR
24
59581-05
BUMPER, rear fender (black) - INTERNATIONAL MODELS ONLY | PR
