WIRING HARNESS, MAIN (CONTINUED)

Harley Davidson FXDSE 1PS8 CVO DYNA (2007)

Harley Davidson
#oem кодцена
70183-07
MAIN WIRING HARNESS (CONTINUED)
51
72231-98
SECONDARY LOCK 3-WAY SOCKET
52
72249-94
SHRINK TUBE (BLACK)
53
72260-04
HOUSING 1-WAY SOCKET (GRAY)
54
72263-95
HOUSING 4-WAY SOCKET (BLACK)
55
72272-07
TERMINAL SOCKET, #14-16 AWG
56
72289-04
TERMINAL SOCKET, #10-12 AWG
57
72290-94
TERMINAL INSULATED
58
72291-94
TERMINAL #14-16 AWG, 56 SERIES
59
72292-94
TERMINAL #12 AWG, 56 SERIES
60
72295-94
HOUSING STARTER CONNECTION
61
72327-03A
CONNECTOR 3-way
62
72330-95
FUSE 15 AMP (BLUE)
63
72414-07BK
HOUSING 6-WAY SOCKET (BLACK)
64
72427-00
TERMINAL .187, #22-16 AWG
65
72430-00
FUSE BLOCK
66
72432-00
FUSE BLOCK
67
72434-00
TERMINAL POWER-TIMER, #16-14 AWG
68
72469-07GY
HOUSING 8-WAY SOCKET (GRAY)
69
72516-01
Пылезащитный колпачок
70
72533-06
DUST CAP 2-PIN CONNECTOR
71
72553-07
DUST CAP 5-PIN CONNECTOR
72
72611-07
TERMINAL SOCKET, #16-20 AWG (GOLD)
73
72612-06BK
HOUSING 2-WAY SOCKET (BLACK)
74
72652-06
SECONDARY LOCK 2-WAY SOCKET
75
72694-06
TERMINAL SOCKET, #10 AWG
76
72914-01BK
HOUSING 4-WAY SOCKET (BLACK)
77
72991-01
TERMINAL SOCKET, #18-22 AWG
78
73103-96BK
HOUSING 3-PLACE PIN
79
73103-96WE
HOUSING 3-WAY PIN
80
73104-96BK
HOUSING 4-PLACE PIN (BLACK)
81
73108-96BK
HOUSING 8-PLACE PIN (BLACK)
82
73190-96
TERMINAL PIN, #16-20 AWG
83
73301-04
HOUSING 2-WAY PIN
84
73303-04
SECONDARY LOCK 2-WAY SOCKET
85
73304-04
TERMINAL #10 AWG
86
73305-04
WIRE SEAL #10 AWG (BLUE)
87
74109-98BK
HOUSING 12-WAY PIN (BLACK)
88
74112-98BK
HOUSING 2-WAY SOCKET (BLACK)
89
74149-98
SECONDARY LOCK 12-WAY PIN
90
74152-98
SECONDARY LOCK 2-WAY SOCKET
91
74190-98
TERMINAL PIN, #16-20 AWG
92
74191-98
TERMINAL SOCKET
93
72033-93
SOCKET TERMINAL
94
72312-04
HOUSING 3-WAY, FEMALE
