Задний бампер

Harley Davidson FLHR 1FB4 ROAD KING (2007)

Harley Davidson
#oem кодцена
1
2604
SCREW NO. 10-32 X 1/2 POZIDRIV PAN HD. (GRADE 2)
4
3676
SCREW 5/16-18 X 5/8 TORX PAN HD.
5
3684
SCREW 5/16-18 X 1 TORX PAN HD.
6
6703
WASHER 1/4 X 5/8 X 1/16
7
7434
WASHER 1/4 X 1-29/64 X 1/16 NYLON
8
7499
NUT 1/4-20 LARGE FLANGE
9
7531
LOCKNUT 5/16-18 X 9/32 X 1/2 FLANGE
10
7629
NUT NO. 10-32 X 3/8 KEPS
11
7683
LOCKNUT 1/4-28 X 5/16 X 7/16
12
7880
NUT 1/2-13 X 7/16 X 3/4 (GRADE 2)
13
8135B
Гайка
14
8144
CLIP NUT
15
59579-06
FENDER REAR (PRIME)
19
59174-99
STUD PLATE
21
59672-99
LAMP ASSEMBLY FENDER TIP, W/ 30, 31, 35 & 37
25
59786-01
FENDER MOUNTING BOSS INNER
26
59788-01
FENDER MOUNTING WASHER
29
67266-94
GROMMET TURN SIGNAL
30
68046-79
LENS REAR FENDER LAMP
31
68193-95
BULB WEDGE
31
68772-06
HARNESS REAR, LIGHTING, (NOT ILLUSTRATED) W/ 10006, 70522-06A, 73156-96BK, 73158-96BK & 73191-96
35
73153-96BK
SOCKET HOUSING 3-PLACE (BLACK)
37
73191-96
TERMINAL SOCKET 16-20 AWG
38
91013-79A
REAR BUMPER ASSEMBLY W/ 13, 39 & 40 (HDI)
39
91023-79A
RAIL REAR BUMPER (HDI)
40
91123-77
BUMPER CUSHION REAR (HDI)
42
2420
SCREW 1/4-20 X 3/4 TRUSS HD. (GRADE 2)
43
2731W
SCREW NO. 10 X 3/8 PHILLIPS TRUSS HD., SELF-TAPPING
44
3574
SCREW 1/4-20 X 3/4 FLANGE
45
7499
NUT 1/4-20 LARGE FLANGE
46
53436-97
BULB WEDGE (HDI)
47
59259-90
REFLECTOR RED (HDI)
48
59117-96
LAMP ASSEMBLY FENDER TIP, W/ 68081-96 (HDI)
49
59292-94
NUT PLASTIC (HDI)
50
60026-97
PLATE LICENSE BACK (HDI)
51
60039-97
BRACKET LICENSE PLATE MOUNTING (HDI)
