Переднее крыло

Harley Davidson FLHTCI 1FFW ELECTRA GLIDE CLASSIC (2003)

Harley Davidson
#oem кодцена
2
2531
SCREW NO. 4-40 X 5/16 POZIDRIV PAN HD. (GRADE 2)
3
2604
SCREW NO. 10-32 X 1/2 POZIDRIV PAN HD. (GRADE 2)
4
3462
BOLT 5/16-18 X 1-1/4 HEX HD. (GRADE 8)
5
3560WA
BOLT NO. 10-24 X 3/8
6
3561WC
BOLT NO. 10-24 X 3/8
8
4091
SCREW NO. 10-24 X 1/2 HEX HD., W/WASHER, SELF-TAPPING (ZINC)
9
6703
WASHER 1/4 X 5/8 X 1/16
10
6716
WASHER NO. 10 X 1/2 X 3/64
11
7220
LOCKWASHER NO. 10 EXTERNAL TOOTH
12
7600
NUT NO. 4-40 KEPS
14
7624
LOCKNUT NO. 10-24 X 1/4 X 3/8
15
7629
NUT NO. 10-32 X 3/8 KEPS
18
8126A
SPEED NUT REFLECTOR
19
10102
Зажим
20
11437
GROMMET WIRING HARNESS
21
13967-99
DECAL in.CLASSICin. (MEDIUM SILVER)
21
14331-90
DECAL in.CLASSICin. (PALE METALLIC GOLD)
23
45279-00
WASHER 11/32 X 5/8 X 1/32 ALUMINUM
25
59093-00B
FENDER (PRIME)
26
59166-80
LOCKPLATE
27
59180-80
LENS FENDER LAMP (AMBER)
28
59211-74A
SIDE TRIM
29
59231-86
TRIM SKIRT LOWER
31
59261-91
REFLECTOR (AMBER)
32
68193-95
BULB FENDER TIP LAMP
33
68706-00
FENDER LIGHT ASSEMBLY
34
70196-00
WIRE ASSEMBLY
35
73102-96BK
HOUSING PIN 2-PLACE
36
73190-96
TERMINAL PIN
37
73191-96
PIN SINGLE SOCKET
38
73152-96BK
SOCKET HOUSING 2-PLACE
39
91085-83D
BUMPER ASSEMBLY W/ 3, 7, 8, 9, 15, 16, 17, 25, 30, 39 & 40
40
91090-77A
BRACKET BUMPER
41
91107-77C
CUSHION BUMPER
