SIDECAR TURN SIGNAL

Harley Davidson TLEU KX97 ULTRA SIDECAR (1997)

Harley Davidson
#oem кодцена
1
2664
SCREW No. 10-24 X 7/16 Pozidriv pan hd. (Grade 2) | GX97/KX97
2
4401W
BOLT 3/8-24 X 2-3/4 hex hd. (Grade 5) | GX97/KX97
3
6416
WASHER 3/8 X 1 X 5/64 | GX97/KX97
4
7069
LOCKWASHER No. 10 | GX97/KX97
5
7780
LOCKNUT 3/8-24 X 13/32 X 11/16 flange | GX97/KX97
6
68402-86
LAMP w/ wire, turn signal (amber) | GX97/KX97
7
68440-86
LENS turn signal | GX97/KX97
8
68452-86
SCREW | GX97/KX97
9
68572-64B
BULB turn signal | GX97/KX97
10
70221-94
WIRING HARNESS w/ 6 & 11-19 | GX97/KX97
11
10065
CABLE STRAP | GX97/KX97
12
72103-94BK
RECEPTACLE 3-way pin | GX97/KX97
13
72104-94BK
RECEPTACLE 4-way pin | GX97/KX97
14
72143-94
PIN LOCK secondary, 3-way | GX97/KX97
15
72144-94
PIN LOCK secondary, 4-way | GX97/KX97
16
72190-94
TERMINAL pin | GX97/KX97
17
72249-94
HEAT SHRINK TUBE .3 x 1 inch | GX97/KX97
18
9857
TERMINAL ring type, #10 hole | GX97/KX97
19
9860
TERMINAL ring type, 3/8 hole | GX97/KX97
20
87120-79
SPACER turn signal & spring shackle | GX97/KX97
21
87121-79
BRACKET turn signal | GX97/KX97
22
88301-79
SHACKLE PLATE w/ bushing, turn signal & spring | GX97/KX97
23
88302-79
SHACKLE PLATE turn signal & spring | GX97/KX97
24
88314-37
BUSHING shackle plate | GX97/KX97
