TAIL LAMP & REAR TURN SIGNALS

Harley Davidson FXDL 1GDL DYNA LOW RIDER (1993)

Harley Davidson
#oem кодцена
1
3409
BOLT 5/16-24 X 3-1/2 HEX HD. (GRADE 5)
2
6701
WASHER 3/8 X 13/16 X 1/16
3
7100
LOCKWASHER 5/16 INTERNAL/EXTERNAL TOOTH
4
7501
SPEED NUT
5
10065
CABLE STRAP
6
68008-73B
TAIL LAMP ASSEMBLY
7
68026-73
SCREW TAIL LAMP
8
68027-90
GASKET TAIL LAMP LENS
9
68033-90
LENS TAIL LAMP (RED)
10
68123-73
GASKET TAIL LAMP HOUSING
11
68168-89A
BULB TAIL LAMP
12
68407-86
LAMP W/WIRE, REAR (AMBER)
15
68452-86
Винт
16
68457-86
LENS TURN SIGNAL
17
68480-93A
SUPPORT REAR LAMP MOUNTING
18
68572-64B
BULB REAR TURN SIGNAL
19
72039-71A
PIN SINGLE SOCKET
20
68010-90
TAIL LAMP ASSEMBLY (HDI)
21
68036-91
REFLECTOR TAIL LAMP (HDI)
22
68032-90
LENS TAIL LAMP (RED) (HDI)
23
68169-90A
BULB TAIL LAMP (HDI)
24
68507-90
LENS TURN SIGNAL (AMBER) (HDI)
25
68163-84
BULB REAR TURN SIGNAL (HDI)
26
68745-93
LAMP W/WIRE, REAR (AMBER) (HDI)
