BOLT, 5/16-18 X 3/4 hex. hd.(Grade 5 steel)

BOLT, 3/8-24 X 1-3/4 hex. hd.(Grade 5 steel)

WASHER, 3/8 X 13/16 X 1/16

LOCKWASHER, 3/8

LOCKWASHER, 5/16

NUT (84 & Early 85 - FXRT)

WIRE TERMINAL, ring type, No. 10 hole - #16-22 wire

CABLE STRAP

Зажим

Уплотнительное кольцо

Уплотнительное кольцо

LABEL, air suspension

VALVE CAP

CAP, fork slider tube

WASHER (84 & Early 85 - FXRT)

Прокладка

Фитинг

Патрубок

Держатель

O-RING, fork slider tube cap

WASHER, fork slider tube cap

VALVE ASSEMBLY, complete (84 & Early 85 - FXRT)

VALVE ASSEMBLY, complete N/A (Late 85 - FXRT)

VALVE BODY (84 & Early 85 - FXRT)

VALVE BODY (Late 85 to * - FXRT; 86 to * - FXRD )

SOLENOID (84 & Early 85 - FXRT)

VALVE ACTUATOR (Late 85 to * - FXRT; 86 to * - FXRD )

ACCUMULATOR

FITTING (84 & Early 85 - FXRT)

FITTING (Late 85 - FXRT)

BOLT, fitting N/A (84 & Early 85 - FXRT)

HOSE, fitting to valve N/A (Late 85 - FXRT)

VALVE STEM ASSEMBLY

VALVE CAP

TERMINAL, socket

HOSE, 3/8 I.D. x 5/8 O.D. reinforced rubber (25 ft.lg.) (84 & Early 85 - FXRT) | NOTE: Hose is sold in bulk length. Cut to required length.
