Деталь HOLE PLUG, siren switch 84 to * - FLH-80

Деталь SCREW NO. 10-24 X 5/8 HEX HD. (GRADE 8)

Деталь SCREW, No. 8-32 X 5/16 Pozidriv pan hd. (Grade 2 steel)

Деталь SCREW, No. 8-32 x 7/16 Pozidriv pan hd. 70 to 83 - FL, FLH, FLH-80, Classic

Деталь SCREW, 10-24 X 1/2 hex socket head (grade 8)

Деталь SCREW, No. 10-24 x 1/2 self tapping Phil. hd. 84 to * - FLH-80

Деталь SCREW, No. 8-32 X 1-7/8 (headless brass)

Деталь BOLT, 5/16-24 x 9/16 hex. hd. 49 to 78 - FL, FLH, FLH-80

Деталь BOLT, 5/16-24 X 1 hex. hd.(Grade 5 steel)

Деталь BOLT, 5/16-24 X 3/4 hex. hd.(Grade 5 steel)

Деталь BOLT, 5/16-24 X 1-1/4 hex. hd.(Grade 5 steel)

Деталь WASHER, No. 8 x 3/8 x 1/32 70 to Early 78 - FL, FLH, FLH-80

Деталь WASHER, No. 8 X 7/16 X 3/64

Деталь WASHER, 5/16 x 15/16 x 3/16 84 to * - FLH-80

Деталь WASHER, 5/16 X 11/16 X 1/16

Деталь LOCKWASHER, 5/16

Деталь LOCKWASHER, No. 10

Деталь LOCKWASHER, No. 8 (4; 5 - 70 & later) 49 to 83 - FL, FLH, FLH-80, Classic

Деталь LOCKWASHER, 3/8 internal tooth

Деталь LOCKWASHER, 3/8 external tooth

Деталь NUT, No. 8-32 X 1/8 X 11/32 hex.(Grade 2 steel)

Деталь LOCKNUT, No. 8-32 x 3/16 x 3/8 hex. 70 to 79 - FL, FLH, FLH-80, Classic

Деталь NUT, 5/16-24 X 1/4 X 1/2 hex.(Grade 2 steel)

Деталь LOCKNUT, 3/8-16 X 7/16 X 9/16 hex.

Деталь NUT, 3/8-16 X 5/16 X 9/16 hex.(Grade 2 steel)

Деталь CONNECTOR, wire 81 to * - FLH-80, Classic

Деталь MOUNTING CLIP, flasher (3 - 84) 49 to 64 - FL, FLH 70 to * - FL, FLH, FLH-80, Classic

Деталь CLAMP, switch wires 49 to 83 - FL, FLH, FLH-80, Classic

Деталь CLAMP, handlebar switch 49 to 83 - FL, FLH, FLH-80, Classic

Деталь CABLE STRAP 70 to * - FL, FLH, FLH-80, Classic

Деталь LABEL, siren & lights 84 to * - FLH-80

Деталь RIVET, 9/64 x 9/32 umbrella hd. 84 to * - FLH-80

Деталь END PLUG, spotlamp bracket Late 78 to 82 - FL, FLH, FLH-80, Classic

Деталь GROSS BAR, handlebar - mount spotlamps & accessories 41 to 78 - FL, FLH, FLH-80, Classic | Consists of besides items 10 & 14: 7753 NUT, 5/16-24 x 1/4 x 1/2 hex. ; 56581-26 CLAMP, bar to handleb

Деталь CLAMP, bar to handlebar 41 to 78 - FL, FLH, FLH-80, Classic

Деталь SPACER, spotlamp brackets 62 to * - FL, FLH, FLH-80, Classic

Деталь LABEL, headlamp housing 70 to * - FL, FLH, FLH-80, Classic

Деталь TOGGLE SWITCH, spotlamp 70 to * - FL, FLH, FLH-80, Classic

Деталь NUT, toggle switch 70 to * - FL, FLH, FLH-80, Classic

Деталь HOLE PLUG, cycle signal 84 to * - FLH-80

Деталь HOLE PLUG, microphone jack 84 to * - FLH-80

Деталь MOUNTING BRACKET

Деталь FLASHER

Деталь SET OF PURSUIT LAMPS & FITTINGS, 12 V. (blue lens) 70 to 82 - FL, FLH, FLH-80

Деталь SET OF PASSING LAMPS & FITTINGS, 12 V. 70 to 82 - FL, FLH, FLH-80, Classic

Деталь SET OF PURSUIT LAMPS & FITTINGS, 12 V. (red lens) 70 to 82 - FL, FLH, FLH-80

Деталь MOUNTING BRACKET, left 62 to * - FL, FLH, FLH-80, Classic

Деталь SET OF PURSUIT LAMPS & FITTINGS, 12 V 70 to 78 - FL, FLH, FLH-80

Деталь MOUNTING BRACKET, right 62 to * - FL, FLH, FLH-80, Classic

Деталь SET OF PURSUIT LAMPS & FITTINGS (red & clear lens) 70 to 78 - FL, FLH, FLH-80

Деталь SPOTLAMP WIRE 62 to * - FL, FLH, FLH-80, Classic

Деталь AUXILIARY LAMP

Деталь PURSUIT LAMP ASSEMBLY red

Деталь AUXILIARY LAMP

Деталь PURSUIT LAMP ASSEMBLY blue

Деталь SCREW, spotlamp door 41 to * - FL, FLH, FLH-80, Classic

Деталь SEALED UNIT AUXILIARY LAMPS

Деталь WIRE CLIP, passing lamp Late 69 to * - FL, FLH, FLH-80, Classic

Деталь SWIVEL WASHER 41 to * - FL, FLH, FLH-80, Classic

Деталь CLAMP BLOCK 62 to 67 - FL, FLH 70 to * - FL, FLH, FLH-80, Classic

Деталь SWIVEL BLOCK 62 to * - FL, FLH, FLH-80, Classic

Деталь BEZEL RING, passing lamps

Деталь SPOTLAMP SEALED UNIT, 6 V. (clear lens) N/A 62 to 64 - FL, FLH

Деталь SPOTLAMP SEALED UNIT, 12 V. (clear lens) 65 to 78 - FL, FLH, FLH-80

Деталь PURSUIT LAMP sealed unit, 12V (red)

Деталь PURSUIT LAMP sealed unit, 12V (blue)

Деталь SUPPORT BAR 68 to 82 - FL, FLH, FLH-80, Classic

Деталь WASHER, 3/8 x 1-1/8 square Late 82 - FLH-80, Classic

Деталь CLAMP BRACKET, spotlamp 68 to Early 82 - FL, FLH, FLH-80, Classic

Деталь CLAMP BRACKET, spotlamp Late 82 - FLH-80, Classic

Деталь END PLUG, spotlamp bracket 68 to Early 78 - FL, FLH, FLH-80

Деталь HANDLEBAR SWITCH, with wires 41 to Early 79 - FL, FLH, FLH-80, Classic

Деталь WIRING HARNESS, pursuit lamp 84 to * - FLH-80

Деталь WIRE, passing lamp (gray) 70 to Early 78 - FL, FLH, FLH-80

Деталь WIRE, toggle switch - passing lamp (blue) 70 to * - FL, FLH, FLH-80, Classic

Деталь WIRE CONNECTOR (2 - 68 to Early 78) 68 to * - FL, FLH, FLH-80, Classic

Деталь BOOT, toggle switch 84 to * - FLH-80

Деталь TOGGLE SWITCH, pursuit lamp 84 to * - FLH-80

Деталь BRACKET, toggle switches 84 to * - FLH-80
