CAMGEAR COVER WITH COMPONENTS

Harley Davidson XR-750 1CH3 Sportster XR 750 (1973) (750 Racer)

Harley Davidson
#oem кодцена
852A
SCREW, camgear cover - 1/4-20 x 1.00 socket hd. | 96 to *
852A
SCREW, camgear cover - 1/4-20 x 1.00 socket hd. | 96 to *
1795A
SCREW, 1/4-20 X 3 hex socket head | 96 to *
1795A
SCREW, 1/4-20 X 3 hex socket head | 96 to *
2821
SCREW, 1/4-20 X 2.25 hex. cap | 96 to
2821
SCREW, 1/4-20 X 2.25 hex. cap | 96 to
6218W
WASHER, screw, camgear cover | 96 to *
6218W
WASHER, screw, camgear cover | 96 to *
6703
WASHER, 1/4 X 5/8 X 1 /16 | 96 to *
3231B
SET SCREW, 1/4-20 x 1/4 socket hd. (plug for cam cover) | 72 thru 95
3231B
SET SCREW, 1/4-20 x 1/4 socket hd. (plug for cam cover) | 72 thru 95
7920R
NUT, pinion shaft | 93 to *
7920R
NUT, pinion shaft | 93 to *
11245R
KEY, pinion shaft | 93 to *
11245R
KEY, pinion shaft | 93 to *
9028R
BALL BEARING, cam shaft - gear cover | 96 to *
9028R
BALL BEARING, cam shaft - gear cover | 96 to *
25223-96R
CAM GEAR COVER - Requires: BEARINGS, SEAL, SET SCREW, SHIFT LEVER SUPPORT BRACKET | 96 to *
25223-96R
CAM GEAR COVER - Requires: BEARINGS, SEAL, SET SCREW, SHIFT LEVER SUPPORT BRACKET | 96 to *
25567-88R
SHAFT, cam & gears - No. 1, 2, 3, 4 | 96 to *
25567-88R
SHAFT, cam & gears - No. 1, 2, 3, 4 | 96 to *
24024-92R
PINION GEAR (green) (key`d) | 93 to *
24024-92R
PINION GEAR (green) (key`d) | 93 to *
24025-92R
PINION GEAR (white) (key`d) | 93 to *
24025-92R
PINION GEAR (white) (key`d) | 93 to *
24026-92R
PINION GEAR (red) (key`d) | 93 to *
24026-92R
PINION GEAR (red) (key`d) | 93 to *
25569-88R
GEAR, No. 1, 2, 3 & 4 cam (green) | 89 to *
25569-88R
GEAR, No. 1, 2, 3 & 4 cam (green) | 89 to *
29699-88R
GEAR, No. 1, 2, 3 & 4 cam (white) | 89 to *
29699-88R
GEAR, No. 1, 2, 3 & 4 cam (white) | 89 to *
29700-88R
GEAR, No. 1, 2, 3 & 4 cam (red) | 89 to *
29700-88R
GEAR, No. 1, 2, 3 & 4 cam (red) | 89 to *
25570-88R
GEAR, No. 2 & 4 cam (green) | 89 to *
25570-88R
GEAR, No. 2 & 4 cam (green) | 89 to *
29701-88R
GEAR, No. 2 & 4 cam (white) | 89 to *
29701-88R
GEAR, No. 2 & 4 cam (white) | 89 to *
29702-88R
GEAR, No. 2 & 4 cam (red) | 89 to *
29702-88R
GEAR, No. 2 & 4 cam (red) | 89 to *
25571-88R
CAM LOBE, intake | 89 to *
25571-88R
CAM LOBE, intake | 89 to *
25572-88R
CAM LOBE, exhaust | 89 to *
24221-51
NEEDLE BEARING, cam shaft (crankcase) | 75 to *
24221-51
NEEDLE BEARING, cam shaft (crankcase) | 75 to *
25301-98R
GASKET, camgear cover | 72 to *
25301-98R
GASKET, camgear cover | 72 to *
25507-88R
PIN, gear drive | 89 to *
25507-88R
PIN, gear drive | 89 to *
25535-74R
SEAL, pinion shaft - camgear cover | 75 to *
25535-74R
SEAL, pinion shaft - camgear cover | 75 to *
25592-74R
NEEDLE BEARING, pinion shaft | 75 to *
25592-74R
NEEDLE BEARING, pinion shaft | 75 to *
34037-52
BUSHING, shifter shaft | 72 to *
34037-52
BUSHING, shifter shaft | 72 to *
34038-94R
BRACKET, shift lever support | 96 to *
34038-94R
BRACKET, shift lever support | 96 to *
35409-74R
THRUST WASHER, splined pinion shaft | 75 thru 92
35412-74R
SHIM, cam - 0.075 | 75 to *
35412-74R
SHIM, cam - 0.075 | 75 to *
35413-74R
SHIM, cam - 0.070 | 75 to *
35413-74R
SHIM, cam - 0.070 | 75 to *
35414-74R
SHIM, cam - 0.065 | 75 to *
35414-74R
SHIM, cam - 0.065 | 75 to *
35415-74R
SHIM, cam - 0.060 | 75 to *
35415-74R
SHIM, cam - 0.060 | 75 to *
35416-74R
SHIM, cam - 0.055 | 75 to *
35416-74R
SHIM, cam - 0.055 | 75 to *
35417-74R
SHIM, cam - 0.050 | 75 to *
35417-74R
SHIM, cam - 0.050 | 75 to *
35418-74R
SHIM, cam - 0.045 | 72 to *
