FRONT FORK - 1971 & 1972

Harley Davidson FX-1200 2CH2 Super Glide 1200 (1972)

Harley Davidson
#oem кодцена
1
2823
SCREW, 5/16-24 X 3/8 Pozidriv truss hd. (w/lockwasher)(Grade 2 steel)
2
4371WA
Болт
3
4411
BOLT, 3/8-24 X 1-3/4 hex. hd.(Grade 5 steel)
4
4726
BOLT, 7/16-20 X 1-1/2 hex. hd.(Grade 5 steel)
5
6218W
WASHER, 1/4 x 7/16 x 1/32 71 & 72 - FX
7
11105
O-RING, damper tube - lower 71 & 72 - FX
8
11164
RETAINING RING, slider tube 71 & 72 - FX
9
45718-71
NUT, fork stem 71 & 72 - FX
10
45739-62B
UPPER BRACKET, with rubber mounts N/A 71 & 72 - FX
11
45751-71TA
FRONT FORK COVER
12
45756-59
CAP AND VALVE, complete N/A 71 & 72 - FX
13
45757-49
BREATHER VALVE 71 & 72 - FX
14
45782-72A
SCREW INSERT 71 & 72 - FX
15
45818-52
BUSHING, slider tube 71 & 72 - FX
16
45975-71
SEAL 71 & 72 - FX
17
46001-71
BOOT N/A 71 & 72 - FX
18
46201-52
DRAIN PLUG, slider N/A 71 & 72 - FX
19
48300-60
BEARING, with cup 71 & 72 - FX
20
48315-60
HEAD CUP 71 & 72 - FX
21
48361-80
DUST SHIELD, head bearing - upper 71 & 72 - FX
22
48365-48A
DUST SHIELD, head bearing - lower 71 & 72 - FX
23
56158-49
RUBBER MOUNT, handlebar 71 & 72 - FX
24
59176-72
NAMEPLATE, front fork - in.SUPER GLIDEin.. N/A 72 - FX
