Передний корпус - облицовка 2

Aprilia Pegaso Strada-Trail 650 IE

Aprilia
#oem кодцена
1
AP8178806
Tank Cover
2
AP8178899
Cover Base
3
AP8104839
Document Holder
4
AP8178900
Fuel Tank Cover
5
AP8144682
Tab
6
AP8102947
Saddle Closing Plate
7
AP8179351
Rh Frame, Black Rx
7
AP8178809
Rh Frame, Grey Sx
8
AP8179352
Lh Frame, Black Sx
8
AP8178808
Lh Frame, Grey Sx
10
AP8178807
Rubber Mat
11
AP8161050
Front Fairing Coil
12
AP8161030
Пружина
13
AP8121184
Screw M4x14
14
AP8104890
Демпфер
15
AP8150413
Inox Self Tapping Screw 3, 9x14
16
AP8144087
Front Lateral Rubber
17
AP8144684
Filler Cap Gasket
18
AP8152226
Hex Socket Screw M6x10*
19
AP8178793
Rh Windshield Support Sx
19
AP8179349
Rh Windshield Support, Black Rx
19
AP8184381
Rh Windshield Support, Grey Fac
20
AP8178794
Lh Windshield Support Sx
20
AP8179350
Lh Windshield Support, Black Rx
20
AP8184382
Lh Windshield Support, Grey Pm
21
AP8102381
Clip M4
22
AP8161056
Штифт
23
AP8161055
Штифт
24
AP8150450
Washer For Shafts D5
25
AP8150444
Self-tapping Screw
26
AP8220488
Mushroom Rubber
27
AP8161077
Coil Bush
28
AP8101944
2-way Union
30
AP8150521
Винт M6x16
31
AP8121129
Втулка
32
AP8152479
Hex Socket Screw M6x30*
33
AP8161082
Spacer Bush
34
AP8152267
Hex Socket Screw M5x12*
35
AP8152246
Винт 6x16
36
AP8152478
Втулка
37
AP8144570
Glove Comp.door Gasket
38
AP8117004
Adhesive Sponge 15x8
39
854616
Acoustic Insulation Panel
