Цилиндр и картер 2

Yamaha F350UCC/F350XCC

Yamaha
#oem кодцена
1
6AW-W009A-01-9S
CYLINDER HEAD COMPLETE
2
6AW-11110-10-00
Голова цилиндра в сборе
3
6S5-11133-10-00
. .GUIDE, VALVE 1
4
91809-08006-00
. .PIN, DOWEL
5
90119-07001-00
. .BOLT, WITH WASHER
6
90119-07234-00
. .BOLT, WITH WASHER
7
90340-18M09-00
. PLUG, STRAIGHT SCREW
8
90201-186F1-00
. .WASHER, PLATE
9
6AW-W009C-01-9S
CYLINDER HEAD 2 COMPLETE
10
6AW-11120-10-00
CYLINDER HEAD ASSY 2
11
6S5-11133-10-00
. .GUIDE, VALVE 1
12
91809-08006-00
. .PIN, DOWEL
13
90119-07001-00
. .BOLT, WITH WASHER
14
90119-07234-00
. .BOLT, WITH WASHER
15
90340-18M09-00
. PLUG, STRAIGHT SCREW
16
90201-186F1-00
. .WASHER, PLATE
17
67F-11301-00-00
Анод в сборе
18
67F-11325-01-00
. .ANODE
19
67F-11328-00-00
. .GROMMET, ANODE
20
90105-06M07-00
. .BOLT, FLANGE
21
90430-06M03-00
. .GASKET
22
95895-08025-00
Болт
23
6AW-11181-00-00
.GASKET, CYLINDER HEAD 1
24
90387-11005-00
Манжета
25
90155-11002-00
SCREW, FLAT FILLISTER
26
90105-08220-00
Болт
27
90119-08115-00
Болт с шайбой
28
6AW-11182-00-00
.GASKET, CYLINDER HEAD 2
29
6AW-11191-10-00
COVER, CYLINDER HEAD 1
30
6AW-11193-10-00
.GASKET, HEAD COVER 1
31
95895-06030-00
Болт
32
6AW-11192-10-00
COVER, CYLINDER HEAD 2
33
6AW-11194-10-00
.GASKET, HEAD COVER 2
34
95895-06030-00
Болт
35
6AW-15142-00-00
Направляющая 1
36
95895-06014-00
Болт
37
LFR-6A110-00-00
PLUG, SPARK (NGK LFR6A-11)
