Electrical - 1
Yamaha F25LEA
| # | oem код | название | цена |
|---|---|---|---|
1 | 6BL-85540-00-00 C.D.I. UNIT ASSY | C.D.I. UNIT ASSY | |
2 | 97575-06520-00 BOLT, WITH WASHER | BOLT, WITH WASHER | |
3 | 6BL-81948-00-00 BRACKET | BRACKET | |
4 | 6A0-82317-00-00 DAMPER, IGNITION COIL | DAMPER, IGNITION COIL | |
5 | 90387-06119-00 COLLAR | COLLAR | |
6 | 95895-06030-00 BOLT, FLANGE | BOLT, FLANGE | |
7 | 90464-13249-00 CLAMP | CLAMP | |
8 | 90464-18246-00 CLAMP | CLAMP | |
9 | 90464-12002-00 CLAMP | CLAMP | |
11 | 97095-06016-00 BOLT | BOLT | |
12 | 92995-06600-00 WASHER | WASHER | |
13 | 6BL-82554-00-00 STAY, NEUTRAL SWITCH | STAY, NEUTRAL SWITCH | |
18 | 95895-06014-00 BOLT, FLANGE | BOLT, FLANGE |
