Корпус редуктора (гребной вал) для лодочных моторов Tohatsu M40C (2004)

Москва и регионы России

Корпус редуктора (гребной вал)

Tohatsu M40C

Корпус редуктора (гребной вал)

#

oem код

название

цена

1

GEAR CASE

GEAR CASE

1

BEARING, 32007

BEARING, 32007

2

Болт

Болт

2

BEVEL GEAR "A"

BEVEL GEAR "A"

2

BEVEL GEAR "A"

BEVEL GEAR "A"

3

Вал гребного винта

Вал гребного винта

4

Муфта сцепления

Муфта сцепления

5

Палец

Палец

6

SNAP, CLUTCH PIN

SNAP, CLUTCH PIN

6

Винт

Винт

7

Пружина

Пружина

7

NYLON NUT, 4P-0.7

NYLON NUT, 4P-0.7

8

SPRING HOLDER, CLUTCH

SPRING HOLDER, CLUTCH

9

PUSH ROD, CLUTCH

PUSH ROD, CLUTCH

10

HOUSING, PROPELLER SHAFT

HOUSING, PROPELLER SHAFT

11

NEEDLE BEARING, 22-30-30

NEEDLE BEARING, 22-30-30

12

OIL SEAL, 22 - 36 - 10

OIL SEAL, 22 - 36 - 10

13

BALL BEARING, 6007

BALL BEARING, 6007

14

O-RING , 3.53 - 69.44

O-RING , 3.53 - 69.44

15

BEVEL GEAR "C"

BEVEL GEAR "C"

15

PUMP CASE UPPER

PUMP CASE UPPER

16

WASHER, 22.1-28-3

WASHER, 22.1-28-3

17

Болт

Болт

17

PUMP CASE LOWER

PUMP CASE LOWER

18

TRUST HOLDER, PROPELLER

TRUST HOLDER, PROPELLER

19

PROPELLER 12, (3 X 10.6 X 11.7)

PROPELLER 12, (3 X 10.6 X 11.7)

19

PROPELLER 10, (3 X 10.8 X 9.9)

PROPELLER 10, (3 X 10.8 X 9.9)

19

PROPELLER 11, (3 X 10.6 X 11.3)

PROPELLER 11, (3 X 10.6 X 11.3)

19

PROPELLER 7, (4 X 11.4 X 7.1)

PROPELLER 7, (4 X 11.4 X 7.1)

19

PROPELLER 14, (3 X 10.2 X 13.9)

PROPELLER 14, (3 X 10.2 X 13.9)

19

PROPELLER 8.5, (3 X 11.2 X 8.7)

PROPELLER 8.5, (3 X 11.2 X 8.7)

19

PROPELLER 13, (3 X 10.3 X 12.7)

PROPELLER 13, (3 X 10.3 X 12.7)

19

PROPELLER 9, (3 X 10.9 X 8.9)

PROPELLER 9, (3 X 10.9 X 8.9)

19

PROPELLER 14, (3 X 10.2 X 13.9)

PROPELLER 14, (3 X 10.2 X 13.9)

20

GUIDE PLATE, WATER PUMP

GUIDE PLATE, WATER PUMP

20

STOPPER, PROPELLER

STOPPER, PROPELLER

21

WASHER, 17-32-3

WASHER, 17-32-3

21

GASKET, PUMP GUIDE PLATE

GASKET, PUMP GUIDE PLATE

22

NUT, PROPELLER

NUT, PROPELLER

22

GASKET, PUMP CASE UPPER

GASKET, PUMP CASE UPPER

23

SPLIT PIN, 3-5

SPLIT PIN, 3-5

24

Триммер

Триммер

24

Болт

Болт

25

GASKET, TRIM TAB

GASKET, TRIM TAB

25

SEAL RUBBER LOWER, WATER PIPE

SEAL RUBBER LOWER, WATER PIPE

26

Болт

Болт

27

SHIM, 36-44-0.15

SHIM, 36-44-0.15

27

SHIM, 36 - 44 - 0.3

SHIM, 36 - 44 - 0.3

27

SHIM, 36-44-0.1

SHIM, 36-44-0.1

28

LOCK RUBBER, WATER PIPE

LOCK RUBBER, WATER PIPE

30

Кулачковый толкатель

Кулачковый толкатель

31

CAM ROD "S"

CAM ROD "S"

31

CAM ROD "L"

CAM ROD "L"

31

CAM ROD "UL"

CAM ROD "UL"

32

SPRING PIN, 3-16

SPRING PIN, 3-16

33

BUSHING, CAM ROD

BUSHING, CAM ROD

34

O-RING, 1.9-6.8

O-RING, 1.9-6.8

35

O-RING, 2.4-15.4

O-RING, 2.4-15.4

36

STOPPER, CAM ROD BUSHING

STOPPER, CAM ROD BUSHING

38

JOINT, SHIFT ROD

JOINT, SHIFT ROD

39

SPRING PIN, 3-12

SPRING PIN, 3-12
