Bracket & Reverse Lock для лодочных моторов Tohatsu M8B (2003)

Москва и регионы России

Bracket & Reverse Lock

Tohatsu M8B

Bracket & Reverse Lock

#

oem код

название

цена

1

STERN BRACKET R

STERN BRACKET R

1

MOTOR COVER LOWER

MOTOR COVER LOWER

2

STEM BRACKET L

STEM BRACKET L

2

SPRING PIN, 3 - 10

SPRING PIN, 3 - 10

3

BOLT, 8 - 122

BOLT, 8 - 122

3

CAM ROD S

CAM ROD S

3

CAM ROD L

CAM ROD L

3

CAM ROD UL

CAM ROD UL

4

NYLON NUT, 8P 1.25

NYLON NUT, 8P 1.25

4

BUSHING, CAM ROD

BUSHING, CAM ROD

5

O-RING, 2.5 - 4.9

O-RING, 2.5 - 4.9

5

Шайба

Шайба

6

O-RING, 2.4 - 15.4

O-RING, 2.4 - 15.4

6

WASHER, 8.5 - 28 -1

WASHER, 8.5 - 28 -1

7

DISTANCE PLATE, BRACKET

DISTANCE PLATE, BRACKET

7

SHIFT LEVER

SHIFT LEVER

8

Винт

Винт

8

OIL SEAL, 14 - 20 - 4.5

OIL SEAL, 14 - 20 - 4.5

9

SPRING, STERN BRACKET

SPRING, STERN BRACKET

9

STARTER LOCK LEVER

STARTER LOCK LEVER

10

Винт

Винт

10

BUSHING, SHIFT LEVER SHAFT

BUSHING, SHIFT LEVER SHAFT

11

SHIFT ROD LEVER

SHIFT ROD LEVER

11

WASHER, 4.3 - 12 - 1.5

WASHER, 4.3 - 12 - 1.5

12

SNAP RETAINER, D=8

SNAP RETAINER, D=8

12

Штанга

Штанга

13

SPRING, THRUST ROD

SPRING, THRUST ROD

13

STOPPER, SHIFT LEVER

STOPPER, SHIFT LEVER

14

CLAMP SCREW ASSY

CLAMP SCREW ASSY

14

Болт

Болт

14-1

CLAMP SCREW

CLAMP SCREW

14-2

HANDLE, CLAMP SCREW

HANDLE, CLAMP SCREW

14-3

PIN, 3 - 22

PIN, 3 - 22

15

PLATE, SHIFT LEVER STOPPER

PLATE, SHIFT LEVER STOPPER

15

PAD, CLAMP SCREW

PAD, CLAMP SCREW

16

SHIFT ROD

SHIFT ROD

16

SWIVEL BRACKET

SWIVEL BRACKET

17

JOINT, SHIFT ROD

JOINT, SHIFT ROD

17

STEERING SHAFT ASSY

STEERING SHAFT ASSY

18

THRUST PLATE

THRUST PLATE

19

E-RING D=10

E-RING D=10

19

O-RING, 4.25 - 19.5

O-RING, 4.25 - 19.5

20

BUSHING, STEERING SHAFT

BUSHING, STEERING SHAFT

21

FRICTION PLATS

FRICTION PLATS

22

Пружина

Пружина

23

Болт

Болт

24

MOUNT RUBBER UPPER

MOUNT RUBBER UPPER

25

Резиновый демпфер

Резиновый демпфер

27

MOUNT BRACKET L

MOUNT BRACKET L

28

Болт

Болт

29

MOUNT RUBBER LOWER, SIDE

MOUNT RUBBER LOWER, SIDE

30

MOUNT RUBBER LOWER, FRONT

MOUNT RUBBER LOWER, FRONT

31

TILT STOPPER ASSY

TILT STOPPER ASSY

31-1

GRIP, TILT STOPPER

GRIP, TILT STOPPER

32

BUSHING, TILT STOPPER

BUSHING, TILT STOPPER

33

COLL SPRING

COLL SPRING

34

SET PLATE, TILT STOPPER

SET PLATE, TILT STOPPER

35

Болт

Болт

36

GREASE NIPPLE

GREASE NIPPLE

37

CAP, GREASE NIPPLE

CAP, GREASE NIPPLE

38

REVERSE LOCK

REVERSE LOCK

39

SHAFT, REVERSE LOCK

SHAFT, REVERSE LOCK

40

E-RING, D=5

E-RING, D=5

41

SPRING, REVERSE LOCK

SPRING, REVERSE LOCK

42

LINK, REVERSE LOCK

LINK, REVERSE LOCK

43

ROD SNAP, 5 - 2.5

ROD SNAP, 5 - 2.5

44

JOINT, REVERSE LOCK LINK

JOINT, REVERSE LOCK LINK
