CLAMP BRACKET (DF100AT E11)

Suzuki Marine DF 100ATL

Suzuki Marine
#oem кодцена
1
41111-90J13-YAY
BRACKET, CLAMP STBD (BLACK)
2
41121-90J21-YAY
BRACKET, CLAMP PORT (BLACK)
3
41130-92J30
SHAFT, CLAMP BRACKET
4
55320-94900
ZINC, PROTECTION
5
09116-06121
BOLT (6X25)
6-1
09100-12091
BOLT (12X115)
6-2
09100-12090
BOLT (12X150) *{OPT}*
7
09159-12014
NUT
8
09159-22006
NUT
9
09160-12128
WASHER (12.5X35X3)
10
09160-12110
WASHER (12.5X22X3)
11
41135-92J00
WASHER, SHAFT
12
09106-10065
BOLT (10X20)
13
09160-10082
WASHER (10.5X19X2)
14
09116-08137
BOLT (8X22)
15
29103-93J00
BOLT, PTT CABLE CLAMP
16
09403-13408
CLAMP
17
45421-90J00
PIN, TILT LOCK *{OPT}*
18
09159-14020
NUT *{OPT}*
19
55321-94910
ANODE (MAGNESIUM) *{OPT}*
20
SPECIAL-NOTE
DF100AT E11
