Clamp Bracket (DF50A E03) для лодочных моторов Suzuki Marine DF 50AVTL2 (2017)

Москва и регионы России

Clamp Bracket (DF50A E03)

Suzuki Marine DF 50AVTL2

Clamp Bracket (DF50A E03)

#

oem код

название

цена

1-2

41111-88L20-Y5S

BRACKET, CLAMP STBD (WHITE)

BRACKET, CLAMP STBD (WHITE)

1-1

41111-88L20-YAY

BRACKET, CLAMP STBD (BLACK)

BRACKET, CLAMP STBD (BLACK)

2-1

41121-88L10-YAY

BRACKET, CLAMP PORT (BLACK)

BRACKET, CLAMP PORT (BLACK)

2-2

41121-88L10-Y5S

BRACKET, CLAMP PORT (WHITE)

BRACKET, CLAMP PORT (WHITE)

3

SHAFT, CLAMP BRACKET

SHAFT, CLAMP BRACKET

4

PIN, TILT LOCK

PIN, TILT LOCK

5

WASHER (12.5X22X2.5)

WASHER (12.5X22X2.5)

6

ANODE, PROTECTION

ANODE, PROTECTION

7

BOLT (6X14)

BOLT (6X14)

8-2

BOLT (12X115) *{OPT}*

BOLT (12X115) *{OPT}*

8-1

BOLT (12X100)

BOLT (12X100)

9

NUT

NUT

10

NUT

NUT

11

WASHER (12.5X35X3.2)

WASHER (12.5X35X3.2)

12

WASHER

WASHER

13

NUT

NUT

14

WASHER (10.5X19X2)

WASHER (10.5X19X2)

15

WASHER, CLAMP BRACKET SHAFT

WASHER, CLAMP BRACKET SHAFT
