Throttle body (df200z e03)

Suzuki Marine DF200T,Z 225,T,Z 250,T,Z,ST

Suzuki Marine
#oem кодцена
1
13130-93J30
Collector
2
13139-93J00
Gasket, Collecto
3
13147-93J00
Gasket, Collecto
4
13138-93J00
Bolt, Collector
5
08322-01087
Washer (0010 Per Pack)
6
13140-93J13
Cover Comp, Coll
7
18590-68H00
Датчик давления
8
13310-93J01
Body Assy, Throt
9
13312-93J00
Hose, Bypass Air
10
13279-10G00
11
13355-93J00
12
13295-10G00
Кольцо
13
13320-93J00
Body Assy, Throt
14
13421-93J00
Gasket, Throttle
15
18137-93J00
Valve, Iac
16
09280-29006
O-ring, Iac Valv
17
01547-06257
Болт 6x25
18
02112-3416B
Винт
19
02162-0520B
Винт
20
13144-93J00
Guard, Throttle
21
13583-93J00
Arm, Link No.1
23
13555-93J00
24
13537-93J00
25
09204-01004
Штифт
26
13553-93J00
Lever, No.1
27
13554-93J00
Lever, No.2
28
02112-35087
29
09160-05043
Шайба
30
13521-93J00
31
13514-93J00
Spacer, Link Sha
32
13599-93J00
Nut, Link Shaft
33
13538-93J00
Washer, Link Sha
34
13541-93J00
Cam, Throttle
35
13542-93J00
Пружина
36
13543-93J00
Spacer, Throttle
37
01500-06307
Болт
38
09160-06036
Washer (0010 Per Pack)
39
01550-06167
Болт
40
01550-08307
Болт
41
08316-10087
Гайка
42
09103-08182
Bolt 8 X 125
43
09103-08134
Болт
44
09108-08267
45
08316-1008A
Гайка
46
61436-93J00
