PTT Motor Transom(X) (DF200T E03)
Suzuki Marine DF 200TX
| # | oem код | название | цена |
|---|---|---|---|
1 | 38100-93J03 MOTOR ASSY, PTT | MOTOR ASSY, PTT | |
2 | 31111-94900 SCREW, YOKE | SCREW, YOKE | |
3 | 31123-94910 O RING | O RING | |
4 | 31133-90J00 BRUSH SET, PLUS | BRUSH SET, PLUS | |
5 | 31133-94900 BRUSH | BRUSH | |
6 | 31135-94900 SPRING | SPRING | |
7 | 31136-90J10 BREAKER | BREAKER | |
8 | 31173-94910 HOLDER, BRUSH | HOLDER, BRUSH | |
9 | 31311-93J00 ARMATURE | ARMATURE | |
10 | 33799-97E00 OIL SEAL | OIL SEAL | |
11 | 31281-92J10 BOLT | BOLT | |
12 | 48585-95E00 O RING | O RING |
