STARTER MOTOR

Honda Marine BF90DK5 XRTA

Honda Marine
#oem кодцена
1
31200-ZY9-H01
STARTER MOTOR ASSY.
2
31207-ZY9-H01
CLUTCH, OVERRUNNING
3
31215-PY3-004
GEAR ASSY., PLANETARY
4
31216-ZY9-003
YOKE
5
31217-ZW1-004
ROTOR
6
31218-PY3-004
BALL, STEEL
7
31226-ZY9-H01
SCREW, PAN (6X22)
8
31227-ZY9-H01
BRUSH SET
9
31229-ZY9-H01
STOPPER SET, SLEEVE
10
31231-ZY9-H01
HOLDER, BRUSH
11
31235-ZY6-003
BRACKET, FR.
12
31236-ZY6-003
BRACKET, RR.
13
31240-ZY9-003
SWITCH ASSY., MAGNET
14
31242-ZY9-H01
SHAFT ASSY., CLUTCH
15
31246-ZY9-H01
SHAFT ASSY., GEAR
16
31250-ZW1-004
LEVER SET
17
31251-ZY9-H01
GEAR ASSY. (INNER)
18
31261-ZW1-004
BOLT A, THROUGH
19
90013-ZY9-M00
BOLT, FLANGE (10X75)
20
90059-ZY9-M00
BOLT, FLANGE (10X35)
21
90107-ZW1-004
SCREW, PAN (5X8)
22
91303-ZY3-000
O-RING (59.4X3.1)
