SILENCER CASE + THROTTLE BODY

Honda Marine BF90DK5 XRTA

Honda Marine
#oem кодцена
1
15171-ZY9-000
PIPE, BREATHER
2
16016-ZY6-003
SCREW SET
3
16400-ZY9-H01
BODY ASSY., THROTTLE
4
16896-ZY9-003
CLAMP B, FUEL TUBE
5
16966-MR5-000
JOINT, FUEL TUBE
6
17315-ZY9-M00
BAND, AIR FLOW
7
17371-ZY9-H00
CASE, MUFFLER
8
17374-ZY9-000
GROMMET, MUFFLER
9
30419-ZY9-003
GROMMET, ELECTRONIC PARTS CASE
10
32128-ZY3-000
BRACKET, SENSOR WIRE
11
37830-RNA-A01
SENSOR ASSY., MAP
12
37835-PGK-A01
O-RING
13
37880-RE1-Z01
SENSOR ASSY., AIR TEMPERATURE
14
37881-P2A-000
GROMMET, TA SENSOR
15
90003-ZZ5-M00
BOLT-WASHER (6X27) (CT200)
16
90006-ZY6-000
SCREW, PAN (5X18)
17
90027-ZY9-M00
BOLT, FLANGE (8X60)
18
90069-ZY9-M00
BOLT, FLANGE (6X25)
19
90508-ZZ5-M00
WASHER, PLAIN (6MM)
20
91403-ZY9-000
TUBE A, BREATHER
21
91404-ZY9-000
TUBE B, BREATHER
22
91405-ZY9-000
TUBE C, BREATHER
23
91503-ZY9-M00
COLLAR, MODULE IGNITION CONTROL CASE (CDI)
24
95003-07008-60M
BULK HOSE, VINYL (4X7X8000) (4X7X190)
