OIL PUMP

Honda Marine BF90DK5 XRTA

Honda Marine
#oem кодцена
1
15100-ZY9-M00
PUMP ASSY., OIL
2
15121-ZY9-000
COVER, OIL PUMP
3
15136-ZY9-000
SHAFT, OIL PUMP
4
15231-PE0-000
VALVE, RELIEF
5
15232-PG6-000
SPRING, RELIEF VALVE
6
15234-PC6-000
WASHER, SEALING (18MM)
7
15236-ZY9-M00
BOLT, SEALING (18MM)
8
15331-ZW1-000
ROTOR (INNER)
9
15341-ZW1-000
ROTOR (OUTER)
10
90027-ZY9-M00
BOLT, FLANGE (8X60)
11
90055-ZZ5-M00
BOLT, FLANGE (8X40)
12
90104-ZZ5-M00
BOLT, FLANGE (6X18) (CT200)
13
90456-MC7-000
WASHER, THRUST (13MM)
14
91302-ZW1-000
O-RING, PUMP COVER
15
91304-ZY9-000
O-RING, OIL PUMP
16
96220-50178
ROLLER (5X17.8)
