Remote Control (Panel Mount)

Honda Marine BF90DK0 XRTA

Honda Marine
#oem кодцена
1
24800-ZW1-V21
BOX ASSY., REMOTE CONTROL (PANEL MOUNT) (NA USE ALT:06240-ZW7-U00) | (Optional).
2
24811-ZW1-V21
HANDLE, REMOTE CONTROL | (Optional).
3
24812-ZW1-V21
LEVER, HANDLE LOCK | (Optional).
4
24813-ZW1-V21
GRIP, REMOTE CONTROL HANDLE | (Optional).
5
24816-ZW1-V21
SPRING, REMOTE CONTROL HANDLE | (Optional).
6
24819-ZW1-V21
COVER, GRIP | (Optional).
7
24820-ZW1-V21
HOUSING ASSY., REMOTE CONTROL BOX (A) | (Optional).
8
24821-ZW1-003
BUSHING | (Optional).
9
24822-ZW1-V21
BUTTON, THROTTLE | (Optional).
10
24829-ZW1-003
BAND B, CABLE | (Optional).
11
24830-ZW1-V21
HOUSING, REMOTE CONTROL BOX (B) | (Optional).
12
24834-ZW1-003
RETAINER | (Optional).
13
24836-ZW1-V21
HOUSING, REMOTE CONTROL BOX (C) | (Optional).
14
24870-ZW1-V21
HOUSING ASSY. (INNER) (PANEL MOUNT) | (Optional).
15
32167-ZW5-650
HARNESS ASSY., POWER TRIM-TILT | (Optional).
16
35180-ZW1-003
SWITCH ASSY., EMERGENCY STOP | (Optional).
17
35182-ZW1-003
WIRE, EMERGENCY | (Optional).
18
35370-ZW1-V01
SWITCH ASSY., POWER TRIM-TILT (A) | (Optional).
19
87705-ZW1-003
MARK, REMOTE CONTROL (A)(PANEL) | (Optional).
20
87706-ZW1-003
MARK, REMOTE CONTROL (B)(FOR STARBOARD) | (Optional).
20
87707-ZW1-003
MARK, REMOTE CONTROL (C)(FOR PORT) | (Optional).
21
90136-ZW1-003
SCREW A (NOT AVAILABLE) | (Optional).
22
90137-ZW1-003
SCREW B | (Optional).
23
90138-ZW1-003
SCREW C | (Optional).
24
90131-ZW1-003
SCREW SET (1/4-20X16in.) | (Optional).
25
90314-ZW1-003
NUT (1/4X20) | (Optional).
26
90551-ZW1-003
WASHER | (Optional).
