Impeller Pump Kit

Honda Marine BF90DK0 XRTA

Honda Marine
#oem кодцена
1
06192-ZW1-000
PUMP KIT, IMPELLER | (Optional).
2
06193-ZZ0-000
PUMP KIT, IMPELLER | (Optional).
3
19210-ZW1-B04
SEE PART DETAILS - PRI; IMPELLER, PUMP | (Optional).
4
19221-ZY6-000
HOUSING, IMPELLER | (Optional).
5
19223-ZW1-B00
LINER, PUMP | (Optional).
6
19231-ZY6-000
COVER, IMPELLER | (Optional).
7
19234-ZW1-B00
GASKET B, IMPELLER | (Optional).
8
19242-ZW1-B00
GASKET, WATER PUMP | (Optional).
9
19253-ZW1-B01
RING, WATER TUBE SEAL | (Optional).
10
90010-ZV5-000
BOLT, HEX. (8X55) | (Optional).
11
90514-921-000
WASHER (8MM) | (Optional).
12
90752-ZW1-B02
KEY, WOODRUFF | (Optional).
13
91356-ZW1-B00
O-RING, WATER PUMP | (Optional).
14
91552-ZY6-000
COLLAR, DISTANCE | (Optional).
